7UT613/63x Manual
C53000-G1176-C160-2
1151 PoleOpenCurrIX1 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
AuxiliaryCT1
5A 0.20 .. 5.00 A 0.20 A
1152 PoleOpenCurrIX2 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
AuxiliaryCT2
5A 0.20 .. 5.00 A 0.20 A
1153 PoleOpenCurrIX3 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
AuxiliaryCT3
5A 0.20 .. 5.00 A 0.20 A
1154 PoleOpenCurrIX4 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
AuxiliaryCT4
5A 0.20 .. 5.00 A 0.20 A
1201 DIFF. PROT. Diff. Prot OFF
ON
Block relay
OFF Differential Protection
1205 INC.CHAR.START Diff. Prot OFF
ON
OFF Increase of Trip Char. During
Start
1206 INRUSH 2.HARM. Diff. Prot OFF
ON
ON Inrush with 2. Harmonic Restraint
1207 RESTR. n.HARM. Diff. Prot OFF
3. Harmonic
5. Harmonic
OFF n-th Harmonic Restraint
1208 I-DIFF> MON. Diff. Prot OFF
ON
ON Differential Current monitoring
1210 I> CURR. GUARD Diff. Prot 0.20 .. 2.00 I/InS; 0 0.00 I/InS I> for Current Guard
1211A DIFFw.IE1-MEAS Diff. Prot NO
YES
NO Diff-Prot. with meas. Earth
Current S1
1212A DIFFw.IE2-MEAS Diff. Prot NO
YES
NO Diff-Prot. with meas. Earth
Current S2
1213A DIFFw.IE3-MEAS Diff. Prot NO
YES
NO Diff-Prot. with meas. Earth
Current S3
1214A DIFFw.IE4-MEAS Diff. Prot NO
YES
NO Diff-Prot. with meas. Earth
Current S4
1215A DIFFw.IE5-MEAS Diff. Prot NO
YES
NO Diff-Prot. with meas. Earth
Current S5
1216A DIFFw.IE3phMEAS Diff. Prot NO
YES
NO Diff-Prot.with meas.current
earth.electr
1221 I-DIFF> Diff. Prot 0.05 .. 2.00 I/InO 0.20 I/InO Pickup Value of Differential Curr.
1226A T I-DIFF> Diff. Prot 0.00 .. 60.00 sec; ∞ 0.00 sec T I-DIFF> Time Delay
1231 I-DIFF>> Diff. Prot 0.5 .. 35.0 I/InO; ∞ 7.5 I/InO Pickup Value of High Set Trip
1236A T I-DIFF>> Diff. Prot 0.00 .. 60.00 sec; ∞ 0.00 sec T I-DIFF>> Time Delay
1241A SLOPE 1 Diff. Prot 0.10 .. 0.50 0.25 Slope 1 of Tripping Characteristic
1242A BASE POINT 1 Diff. Prot 0.00 .. 2.00 I/InO 0.00 I/InO Base Point for Slope 1 of Charac.
1243A SLOPE 2 Diff. Prot 0.25 .. 0.95 0.50 Slope 2 of Tripping Characteristic
1244A BASE POINT 2 Diff. Prot 0.00 .. 10.00 I/InO 2.50 I/InO Base Point for Slope 2 of Charac.
1251A I-REST. STARTUP Diff. Prot 0.00 .. 2.00 I/InO 0.10 I/InO I-RESTRAINT for Start Detection
1252A START-FACTOR Diff. Prot 1.0 .. 2.0 1.0 Factor for Increasing of Char. at
Start
1253 T START MAX Diff. Prot 0.0 .. 180.0 sec 5.0 sec Maximum Permissible Starting
Time
1261A I-ADD ON STAB. Diff. Prot 2.00 .. 15.00 I/InO 4.00 I/InO Pickup for Add-on Stabilization
1262A T ADD ON-STAB. Diff. Prot 2 .. 250 Cycle; ∞ 15 Cycle Duration of Add-on Stabilization
1263A CROSSB. ADD ON Diff. Prot 2 .. 1000 Cycle; 0; ∞ 15 Cycle Time for Cross-blocking Add-on
Stabiliz.
1271 2. HARMONIC Diff. Prot 10 .. 80 % 15 % 2nd Harmonic Content in I-DIFF
1272A CROSSB. 2. HARM Diff. Prot 2 .. 1000 Cycle; 0; ∞ 3 Cycle Time for Cross-blocking 2nd
Harm.
1276 n. HARMONIC Diff. Prot 10 .. 80 % 30 % n-th Harmonic Content in I-DIFF
1277A CROSSB. n.HARM Diff. Prot 2 .. 1000 Cycle; 0; ∞ 0 Cycle Time for Cross-blocking n-th
Harm.
1278A IDIFFmax n.HM Diff. Prot 0.5 .. 20.0 I/InO 1.5 I/InO Limit IDIFFmax of n-th Harm.Re-
straint
1281 I-DIFF> MON. Diff. Prot 0.15 .. 0.80 I/InO 0.20 I/InO Pickup Value of diff. Current
Monitoring
1282 T I-DIFF> MON. Diff. Prot 1 .. 10 sec 2 sec T I-DIFF> Monitoring Time Delay
