A.8 Settings
569
7UT613/63x Manual
C53000-G1176-C160-2
3027 ANSI CURVE Phase O/C 2 Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
3031 I/Ip PU T/Tp Phase O/C 2 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
Pickup Curve I/Ip - TI/TIp
3032 MofPU Res T/Tp Phase O/C 2 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
Multiple of Pickup <-> TI/TIp
3041 2.HARM. Phase Phase O/C 2 10 .. 45 % 15 % 2nd harmonic O/C Ph. in % of
fundamental
3042 I Max InRr. Ph. Phase O/C 2 1A 0.30 .. 25.00 A 7.50 A Maximum Current for Inr. Rest.
O/C Phase
5A 1.50 .. 125.00 A 37.50 A
3043 I Max InRr. Ph. Phase O/C 2 0.30 .. 25.00 I/InS 7.50 I/InS Maximum Current for Inr. Rest.
O/C Phase
3044 CROSS BLK.Phase Phase O/C 2 NO
YES
NO CROSS BLOCK O/C Phase
3045 T CROSS BLK.Ph Phase O/C 2 0.00 .. 180.00 sec 0.00 sec CROSS BLOCK Time O/C
Phase
3111 I>> Phase O/C 2 1A 0.10 .. 35.00 A; ∞ 10.00 A I>> Pickup
5A 0.50 .. 175.00 A; ∞ 50.00 A
3112 I>> Phase O/C 2 0.10 .. 35.00 I/InS; ∞ 10.00 I/InS I>> Pickup
3113 T I>> Phase O/C 2 0.00 .. 60.00 sec; ∞ 0.10 sec T I>> Time Delay
3114 I> Phase O/C 2 1A 0.10 .. 35.00 A; ∞ 4.00 A I> Pickup
5A 0.50 .. 175.00 A; ∞ 20.00 A
3115 I> Phase O/C 2 0.10 .. 35.00 I/InS; ∞ 4.00 I/InS I> Pickup
3116 T I> Phase O/C 2 0.00 .. 60.00 sec; ∞ 0.30 sec T I> Time Delay
3121 Ip Phase O/C 2 1A 0.10 .. 4.00 A 4.00 A Ip Pickup
5A 0.50 .. 20.00 A 20.00 A
3122 Ip Phase O/C 2 0.10 .. 4.00 I/InS 4.00 I/InS Ip Pickup
3123 T Ip Phase O/C 2 0.05 .. 3.20 sec; ∞ 0.50 sec T Ip Time Dial
3124 D Ip Phase O/C 2 0.50 .. 15.00 ; ∞ 5.00 D Ip Time Dial
3201 PHASE O/C Phase O/C 3 ON
OFF
Block relay
OFF Phase Time Overcurrent
3202 InRushRest. Ph Phase O/C 3 ON
OFF
OFF InRush Restrained O/C Phase
3208A MANUAL CLOSE Phase O/C 3 I>> instant.
I> instant.
Ip instant.
Inactive
I>> instant. O/C Manual Close Mode
3211 I>> Phase O/C 3 1A 0.10 .. 35.00 A; ∞ 4.00 A I>> Pickup
5A 0.50 .. 175.00 A; ∞ 20.00 A
3212 I>> Phase O/C 3 0.10 .. 35.00 I/InS; ∞ 4.00 I/InS I>> Pickup
3213 T I>> Phase O/C 3 0.00 .. 60.00 sec; ∞ 0.10 sec T I>> Time Delay
3214 I> Phase O/C 3 1A 0.10 .. 35.00 A; ∞ 2.00 A I> Pickup
5A 0.50 .. 175.00 A; ∞ 10.00 A
3215 I> Phase O/C 3 0.10 .. 35.00 I/InS; ∞ 2.00 I/InS I> Pickup
3216 T I> Phase O/C 3 0.00 .. 60.00 sec; ∞ 0.30 sec T I> Time Delay
3221 Ip Phase O/C 3 1A 0.10 .. 4.00 A 2.00 A Ip Pickup
5A 0.50 .. 20.00 A 10.00 A
3222 Ip Phase O/C 3 0.10 .. 4.00 I/InS 2.00 I/InS Ip Pickup
3223 T Ip Phase O/C 3 0.05 .. 3.20 sec; ∞ 0.50 sec T Ip Time Dial
3224 D Ip Phase O/C 3 0.50 .. 15.00 ; ∞ 5.00 D Ip Time Dial
3225 TOC DROP-OUT Phase O/C 3 Instantaneous
Disk Emulation
Disk Emulation TOC Drop-out characteristic
3226 IEC CURVE Phase O/C 3 Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
Addr. Parameter Function C Setting Options Default Setting Comments
