A Appendix
570
7UT613/63x Manual
C53000-G1176-C160-2
3227 ANSI CURVE Phase O/C 3 Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
3231 I/Ip PU T/Tp Phase O/C 3 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
Pickup Curve I/Ip - TI/TIp
3232 MofPU Res T/Tp Phase O/C 3 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
Multiple of Pickup <-> TI/TIp
3241 2.HARM. Phase Phase O/C 3 10 .. 45 % 15 % 2nd harmonic O/C Ph. in % of
fundamental
3242 I Max InRr. Ph. Phase O/C 3 1A 0.30 .. 25.00 A 7.50 A Maximum Current for Inr. Rest.
O/C Phase
5A 1.50 .. 125.00 A 37.50 A
3243 I Max InRr. Ph. Phase O/C 3 0.30 .. 25.00 I/InS 7.50 I/InS Maximum Current for Inr. Rest.
O/C Phase
3244 CROSS BLK.Phase Phase O/C 3 NO
YES
NO CROSS BLOCK O/C Phase
3245 T CROSS BLK.Ph Phase O/C 3 0.00 .. 180.00 sec 0.00 sec CROSS BLOCK Time O/C
Phase
3311 I>> Phase O/C 3 1A 0.10 .. 35.00 A; ∞ 10.00 A I>> Pickup
5A 0.50 .. 175.00 A; ∞ 50.00 A
3312 I>> Phase O/C 3 0.10 .. 35.00 I/InS; ∞ 10.00 I/InS I>> Pickup
3313 T I>> Phase O/C 3 0.00 .. 60.00 sec; ∞ 0.10 sec T I>> Time Delay
3314 I> Phase O/C 3 1A 0.10 .. 35.00 A; ∞ 4.00 A I> Pickup
5A 0.50 .. 175.00 A; ∞ 20.00 A
3315 I> Phase O/C 3 0.10 .. 35.00 I/InS; ∞ 4.00 I/InS I> Pickup
3316 T I> Phase O/C 3 0.00 .. 60.00 sec; ∞ 0.30 sec T I> Time Delay
3321 Ip Phase O/C 3 1A 0.10 .. 4.00 A 4.00 A Ip Pickup
5A 0.50 .. 20.00 A 20.00 A
3322 Ip Phase O/C 3 0.10 .. 4.00 I/InS 4.00 I/InS Ip Pickup
3323 T Ip Phase O/C 3 0.05 .. 3.20 sec; ∞ 0.50 sec T Ip Time Dial
3324 D Ip Phase O/C 3 0.50 .. 15.00 ; ∞ 5.00 D Ip Time Dial
3401 3I0 O/C 3I0 O/C 2 ON
OFF
Block relay
OFF 3I0 Time Overcurrent
3402 InRushRest. 3I0 3I0 O/C 2 ON
OFF
OFF InRush Restrained O/C 3I0
3408A 3I0 MAN. CLOSE 3I0 O/C 2 3I0>> instant.
3I0> instant.
3I0p instant.
Inactive
3I0>> instant. O/C 3I0 Manual Close Mode
3411 3I0>> 3I0 O/C 2 1A 0.05 .. 35.00 A; ∞ 1.00 A 3I0>> Pickup
5A 0.25 .. 175.00 A; ∞ 5.00 A
3412 3I0>> 3I0 O/C 2 0.05 .. 35.00 I/InS; ∞ 1.00 I/InS 3I0>> Pickup
3413 T 3I0>> 3I0 O/C 2 0.00 .. 60.00 sec; ∞ 1.50 sec T 3I0>> Time Delay
3414 3I0> 3I0 O/C 2 1A 0.05 .. 35.00 A; ∞ 0.40 A 3I0> Pickup
5A 0.25 .. 175.00 A; ∞ 2.00 A
3415 3I0> 3I0 O/C 2 0.05 .. 35.00 I/InS; ∞ 0.40 I/InS 3I0> Pickup
3416 T 3I0> 3I0 O/C 2 0.00 .. 60.00 sec; ∞ 2.00 sec T 3I0> Time Delay
3421 3I0p 3I0 O/C 2 1A 0.05 .. 4.00 A 0.40 A 3I0p Pickup
5A 0.25 .. 20.00 A 2.00 A
3422 3I0p 3I0 O/C 2 0.05 .. 4.00 I/InS 0.40 I/InS 3I0p Pickup
3423 T 3I0p 3I0 O/C 2 0.05 .. 3.20 sec; ∞ 0.50 sec T 3I0p Time Dial
3424 D 3I0p 3I0 O/C 2 0.50 .. 15.00 ; ∞ 5.00 D 3I0p Time Dial
3425 TOC DROP-OUT 3I0 O/C 2 Instantaneous
Disk Emulation
Disk Emulation TOC Drop-out Characteristic
3426 IEC CURVE 3I0 O/C 2 Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
Addr. Parameter Function C Setting Options Default Setting Comments
