A Appendix
574
7UT613/63x Manual
C53000-G1176-C160-2
4208A T EMERGENCY Therm. Overload 10 .. 15000 sec 100 sec Emergency Time
4209A I MOTOR START Therm. Overload 0.60 .. 10.00 I/InS; ∞∞I/InS Current Pickup Value of Motor
Starting
4210 TEMPSENSOR RTD Therm. Overload 1 .. 6 1 Temperature sensor connected
to RTD
4211 TEMPSENSOR RTD Therm. Overload 1 .. 12 1 Temperature sensor connected
to RTD
4212 TEMP. RISE I Therm. Overload 40 .. 200 °C100°C Temperature Rise at Rated Sec.
Curr.
4213 TEMP. RISE I Therm. Overload 104 .. 392 °F212°F Temperature Rise at Rated Sec.
Curr.
4220 OIL-DET. RTD Therm. Overload 1 .. 6 1 Oil-Detector conected at RTD
4221 OIL Sensor RTD Therm. Overload 1 .. 12 1 Oil sensor connected to RTD
4222 HOT SPOT ST. 1 Therm. Overload 98 .. 140 °C98°C Hot Spot Temperature Stage 1
Pickup
4223 HOT SPOT ST. 1 Therm. Overload 208 .. 284 °F208°F Hot Spot Temperature Stage 1
Pickup
4224 HOT SPOT ST. 2 Therm. Overload 98 .. 140 °C108°C Hot Spot Temperature Stage 2
Pickup
4225 HOT SPOT ST. 2 Therm. Overload 208 .. 284 °F226°F Hot Spot Temperature Stage 2
Pickup
4226 AG. RATE ST. 1 Therm. Overload 0.200 .. 128.000 1.000 Aging Rate STAGE 1 Pickup
4227 AG. RATE ST. 2 Therm. Overload 0.200 .. 128.000 2.000 Aging Rate STAGE 2 Pickup
4231 METH. COOLING Therm. Overload ON
OF
OD
ON Method of Cooling
4232 Y-WIND.EXPONENT Therm. Overload 1.6 .. 2.0 1.6 Y-Winding Exponent
4233 HOT-SPOT GR Therm. Overload 22 .. 29 22 Hot-spot to top-oil gradient
4301 OVEREXC. PROT. Overexcit. OFF
ON
Block relay
OFF Overexcitation Protection (U/f)
4302 U/f > Overexcit. 1.00 .. 1.20 1.10 U/f > Pickup
4303 T U/f > Overexcit. 0.00 .. 60.00 sec; ∞ 10.00 sec T U/f > Time Delay
4304 U/f >> Overexcit. 1.00 .. 1.40 1.40 U/f >> Pickup
4305 T U/f >> Overexcit. 0.00 .. 60.00 sec; ∞ 1.00 sec T U/f >> Time Delay
4306 t(U/f=1.05) Overexcit. 0 .. 20000 sec 20000 sec U/f = 1.05 Time Delay
4307 t(U/f=1.10) Overexcit. 0 .. 20000 sec 6000 sec U/f = 1.10 Time Delay
4308 t(U/f=1.15) Overexcit. 0 .. 20000 sec 240 sec U/f = 1.15 Time Delay
4309 t(U/f=1.20) Overexcit. 0 .. 20000 sec 60 sec U/f = 1.20 Time Delay
4310 t(U/f=1.25) Overexcit. 0 .. 20000 sec 30 sec U/f = 1.25 Time Delay
4311 t(U/f=1.30) Overexcit. 0 .. 20000 sec 19 sec U/f = 1.30 Time Delay
4312 t(U/f=1.35) Overexcit. 0 .. 20000 sec 13 sec U/f = 1.35 Time Delay
4313 t(U/f=1.40) Overexcit. 0 .. 20000 sec 10 sec U/f = 1.40 Time Delay
4314 T COOL DOWN Overexcit. 0 .. 20000 sec 3600 sec Time for cool down
4401 THERM. OVERLOAD Therm.Overload2 OFF
ON
Block relay
Alarm Only
OFF Thermal Overload Protection
4402 K-FACTOR Therm.Overload2 0.10 .. 4.00 1.10 K-Factor
4403 TIME CONSTANT Therm.Overload2 1.0 .. 999.9 min 100.0 min Thermal Time Constant
4404 Θ ALARM Therm.Overload2 50 .. 100 % 90 % Thermal Alarm Stage
4405 I ALARM Therm.Overload2 0.10 .. 4.00 I/InS 1.00 I/InS Current Overload Alarm Setpoint
4407A Kτ-FACTOR Therm.Overload2 1.0 .. 10.0 1.0 Kt-FACTOR when motor stops
4408A T EMERGENCY Therm.Overload2 10 .. 15000 sec 100 sec Emergency Time
4409A I MOTOR START Therm.Overload2 0.60 .. 10.00 I/InS; ∞∞I/InS Current Pickup Value of Motor
Starting
4410 TEMPSENSOR RTD Therm.Overload2 1 .. 6 1 Temperature sensor connected
to RTD
4411 TEMPSENSOR RTD Therm.Overload2 1 .. 12 1 Temperature sensor connected
to RTD
Addr. Parameter Function C Setting Options Default Setting Comments
