A.8 Settings
575
7UT613/63x Manual
C53000-G1176-C160-2
4412 TEMP. RISE I Therm.Overload2 40 .. 200 °C 100 °C Temperature Rise at Rated Sec.
Curr.
4413 TEMP. RISE I Therm.Overload2 104 .. 392 °F 212 °F Temperature Rise at Rated Sec.
Curr.
4420 OIL-DET. RTD Therm.Overload2 1 .. 6 1 Oil-Detector conected at RTD
4421 OIL Sensor RTD Therm.Overload2 1 .. 12 1 Oil sensor connected to RTD
4422 HOT SPOT ST. 1 Therm.Overload2 98 .. 140 °C98°C Hot Spot Temperature Stage 1
Pickup
4423 HOT SPOT ST. 1 Therm.Overload2 208 .. 284 °F 208 °F Hot Spot Temperature Stage 1
Pickup
4424 HOT SPOT ST. 2 Therm.Overload2 98 .. 140 °C 108 °C Hot Spot Temperature Stage 2
Pickup
4425 HOT SPOT ST. 2 Therm.Overload2 208 .. 284 °F 226 °F Hot Spot Temperature Stage 2
Pickup
4426 AG. RATE ST. 1 Therm.Overload2 0.200 .. 128.000 1.000 Aging Rate STAGE 1 Pickup
4427 AG. RATE ST. 2 Therm.Overload2 0.200 .. 128.000 2.000 Aging Rate STAGE 2 Pickup
4431 METH. COOLING Therm.Overload2 ON
OF
OD
ON Method of Cooling
4432 Y-WIND.EXPONENT Therm.Overload2 1.6 .. 2.0 1.6 Y-Winding Exponent
4433 HOT-SPOT GR Therm.Overload2 22 .. 29 22 Hot-spot to top-oil gradient
5001 REVERSE POWER Reverse Power OFF
ON
Block relay
OFF Reverse Power Protection
5011 P> REVERSE Reverse Power 1A -3000.0 .. -1.7 W -8.7 W P> Reverse Pickup
5A -15000.0 .. -8.5 W -43.5 W
5012 Pr pick-up Reverse Power -17.00 .. -0.01 P/SnS -0.05 P/SnS Pick-up threshold reverse power
5013 T-SV-OPEN Reverse Power 0.00 .. 60.00 sec; ∞ 10.00 sec Time Delay Long (without Stop
Valve)
5014 T-SV-CLOSED Reverse Power 0.00 .. 60.00 sec; ∞ 1.00 sec Time Delay Short (with Stop
Valve)
5015A T-HOLD Reverse Power 0.00 .. 60.00 sec; ∞ 0.00 sec Pickup Holding Time
5016A Type of meas. Reverse Power accurate
fast
accurate Type of measurement
5101 FORWARD POWER Forward Power OFF
ON
Block relay
OFF Forward Power Supervision
5111 Pf< Forward Power 1A 1.7 .. 3000.0 W 17.3 W P-forw.< Supervision Pickup
5A 8.5 .. 15000.0 W 86.5 W
5112 P< fwd Forward Power 0.01 .. 17.00 P/SnS 0.10 P/SnS Pick-up threshold P<
5113 T-Pf< Forward Power 0.00 .. 60.00 sec; ∞ 10.00 sec T-P-forw.< Time Delay
5114 Pf> Forward Power 1A 1.7 .. 3000.0 W 164.5 W P-forw.> Supervision Pickup
5A 8.5 .. 15000.0 W 822.5 W
5115 P> fwd Forward Power 0.01 .. 17.00 P/SnS 0.95 P/SnS Pick-up threshold P>
5116 T-Pf> Forward Power 0.00 .. 60.00 sec; ∞ 10.00 sec T-P-forw.> Time Delay
5117A MEAS. METHOD Forward Power accurate
fast
accurate Method of Operation
5201 UNDERVOLTAGE Undervoltage OFF
ON
Block relay
OFF Undervoltage Protection
5211 U< Undervoltage 10.0 .. 125.0 V 75.0 V U< Pickup
5212 U< Undervoltage 0.10 .. 1.25 U/UnS 0.75 U/UnS Pick-up voltage U<
5213 T U< Undervoltage 0.00 .. 60.00 sec; ∞ 3.00 sec T U< Time Delay
5214 U<< Undervoltage 10.0 .. 125.0 V 65.0 V U<< Pickup
5215 U<< Undervoltage 0.10 .. 1.25 U/UnS 0.65 U/UnS Pick-up voltage U<<
5216 T U<< Undervoltage 0.00 .. 60.00 sec; ∞ 0.50 sec T U<< Time Delay
5217A DOUT RATIO Undervoltage 1.01 .. 1.20 1.05 U<, U<< Drop Out Ratio
5301 OVERVOLTAGE Overvoltage OFF
ON
Block relay
OFF Overvoltage Protection
5311 U> Overvoltage 30.0 .. 170.0 V 115.0 V U> Pickup
Addr. Parameter Function C Setting Options Default Setting Comments
