A Appendix
576
7UT613/63x Manual
C53000-G1176-C160-2
5312 U> Overvoltage 0.30 .. 1.70 U/UnS 1.15 U/UnS Pick-up voltage U>
5313 T U> Overvoltage 0.00 .. 60.00 sec; ∞ 3.00 sec T U> Time Delay
5314 U>> Overvoltage 30.0 .. 170.0 V 130.0 V U>> Pickup
5315 U>> Overvoltage 0.30 .. 1.70 U/UnS 1.30 U/UnS Pick-up voltage U>>
5316 T U>> Overvoltage 0.00 .. 60.00 sec; ∞ 0.50 sec T U>> Time Delay
5317A DOUT RATIO Overvoltage 0.90 .. 0.99 0.95 U>, U>> Drop Out Ratio
5318A VALUES Overvoltage U-ph-ph
U-ph-e
U-ph-ph Measurement Values
5601 O/U FREQUENCY Frequency Prot. OFF
ON
Block relay
OFF Over / Under Frequency Protec-
tion
5611 f< Frequency Prot. 40.00 .. 49.99 Hz; 0 49.50 Hz Pick-up frequency f<
5612 f<< Frequency Prot. 40.00 .. 49.99 Hz; 0 48.00 Hz Pick-up frequency f<<
5613 f<<< Frequency Prot. 40.00 .. 49.99 Hz; 0 47.00 Hz Pick-up frequency f<<<
5614 f> Frequency Prot. 50.01 .. 66.00 Hz; ∞ 52.00 Hz Pick-up frequency f>
5621 f< Frequency Prot. 50.00 .. 59.99 Hz; 0 59.50 Hz Pick-up frequency f<
5622 f<< Frequency Prot. 50.00 .. 59.99 Hz; 0 58.00 Hz Pick-up frequency f<<
5623 f<<< Frequency Prot. 50.00 .. 59.99 Hz; 0 57.00 Hz Pick-up frequency f<<<
5624 f> Frequency Prot. 60.01 .. 66.00 Hz; ∞ 62.00 Hz Pick-up frequency f>
5631 f< Frequency Prot. 10.00 .. 16.69 Hz; 0 16.50 Hz Pick-up frequency f<
5632 f<< Frequency Prot. 10.00 .. 16.69 Hz; 0 16.00 Hz Pick-up frequency f<<
5633 f<<< Frequency Prot. 10.00 .. 16.69 Hz; 0 15.70 Hz Pick-up frequency f<<<
5634 f> Frequency Prot. 16.67 .. 22.00 Hz; ∞ 17.40 Hz Pick-up frequency f>
5641 T f< Frequency Prot. 0.00 .. 100.00 sec; ∞ 20.00 sec Delay time T f<
5642 T f<< Frequency Prot. 0.00 .. 600.00 sec; ∞ 1.00 sec Delay time T f<<
5643 T f<<< Frequency Prot. 0.00 .. 100.00 sec; ∞ 6.00 sec Delay time T f<<<
5644 T f> Frequency Prot. 0.00 .. 100.00 sec; ∞ 10.00 sec Delay time T f>
5651 Umin Frequency Prot. 10.0 .. 125.0 V; 0 65.0 V Minimum Required Voltage for
Operation
5652 U MIN Frequency Prot. 0.10 .. 1.25 U/UnS; 0 0.65 U/UnS Minimum voltage
7001 BREAKER FAILURE Breaker Failure OFF
ON
Block relay
OFF Breaker Failure Protection
7011 START WITH REL. Breaker Failure 0 .. 8 0 Start with Relay (intern)
7012 START WITH REL. Breaker Failure 0 .. 24 0 Start with Relay (intern)
7015 T1 Breaker Failure 0.00 .. 60.00 sec; ∞ 0.15 sec T1, Delay of 1st stage (local trip)
7016 T2 Breaker Failure 0.00 .. 60.00 sec; ∞ 0.30 sec T2, Delay of 2nd stage (busbar
trip)
7101 BREAKER FAILURE Breaker Fail. 2 OFF
ON
Block relay
OFF Breaker Failure Protection
7111 START WITH REL. Breaker Fail. 2 0 .. 8 0 Start with Relay (intern)
7112 START WITH REL. Breaker Fail. 2 0 .. 24 0 Start with Relay (intern)
7115 T1 Breaker Fail. 2 0.00 .. 60.00 sec; ∞ 0.15 sec T1, Delay of 1st stage (local trip)
7116 T2 Breaker Fail. 2 0.00 .. 60.00 sec; ∞ 0.30 sec T2, Delay of 2nd stage (busbar
trip)
7601 POWER CALCUL. Measurement with V setting
with V measur.
with V setting Calculation of Power
7611 DMD Interval Demand meter 15 Min., 1 Sub
15 Min., 3 Subs
15 Min.,15 Subs
30 Min., 1 Sub
60 Min., 1 Sub
60 Min.,10 Subs
5 Min., 5 Subs
60 Min., 1 Sub Demand Calculation Intervals
7612 DMD Sync.Time Demand meter On The Hour
15 After Hour
30 After Hour
45 After Hour
On The Hour Demand Synchronization Time
7621 MinMax cycRESET Min/Max meter NO
YES
YES Automatic Cyclic Reset Function
Addr. Parameter Function C Setting Options Default Setting Comments
