A Appendix
586
7UT613/63x Manual
C53000-G1176-C160-2
033.2413 Undervoltage protection is
ACTIVE (Undervolt. ACT)
Undervoltage OUT ON
OFF
ON
OFF
* LED BO 74 32 1 Yes
033.2491 Undervoltage: Not avail. for this
obj. (U< err. Obj.)
Undervoltage OUT ON * * LED BO
033.2492 Undervoltage: error assigned VT
(U< err. VT)
Undervoltage OUT ON * * LED BO
033.2502 >BLOCK undervoltage protection
U<< (>BLOCK U<<)
Undervoltage SP ON
OFF
ON
OFF
* LED BI BO 74 8 1 Yes
033.2503 >BLOCK undervoltage protection
U< (>BLOCK U<)
Undervoltage SP ON
OFF
ON
OFF
* LED BI BO 74 6 1 Yes
033.2521 Undervoltage U<< picked up
(U<< picked up)
Undervoltage OUT * ON
OFF
* LED BO 74 37 2 Yes
033.2522 Undervoltage U< picked up (U<
picked up)
Undervoltage OUT * ON
OFF
* LED BO 74 33 2 Yes
033.2551 Undervoltage U<< TRIP (U<<
TRIP)
Undervoltage OUT * ON * LED BO 74 40 2 Yes
033.2552 Undervoltage U< TRIP (U< TRIP) Undervoltage OUT * ON * LED BO 74 39 2 Yes
034.2404 >BLOCK overvoltage protection
(>BLOCK O/V)
Overvoltage SP * * * LED BI BO
034.2411 Overvoltage protection is
switched OFF (Overvolt. OFF)
Overvoltage OUT ON
OFF
**LEDBO74651Yes
034.2412 Overvoltage protection is
BLOCKED (Overvolt. BLK)
Overvoltage OUT ON
OFF
ON
OFF
* LED BO 74 66 1 Yes
034.2413 Overvoltage protection is
ACTIVE (Overvolt. ACT)
Overvoltage OUT ON
OFF
ON
OFF
* LED BO 74 67 1 Yes
034.2491 Overvoltage: Not avail. for this
obj. (U> err. Obj.)
Overvoltage OUT ON * * LED BO
034.2492 Overvoltage: error VT assign-
ment (U> err. VT)
Overvoltage OUT ON * * LED BO
034.2502 >BLOCK overvoltage protection
U>> (>BLOCK U>>)
Overvoltage SP ON
OFF
ON
OFF
* LED BI BO 74 21 1 Yes
034.2503 >BLOCK overvoltage protection
U> (>BLOCK U>)
Overvoltage SP ON
OFF
ON
OFF
* LED BI BO 74 20 1 Yes
034.2521 Overvoltage U>> picked up (U>>
picked up)
Overvoltage OUT * ON
OFF
* LED BO 74 71 2 Yes
034.2522 Overvoltage U> picked up (U>
picked up)
Overvoltage OUT * ON
OFF
* LED BO 74 68 2 Yes
034.2551 Overvoltage U>> TRIP (U>>
TRIP)
Overvoltage OUT * ON * LED BO 74 73 2 Yes
034.2552 Overvoltage U> TRIP (U> TRIP) Overvoltage OUT * ON * LED BO 74 70 2 Yes
044.2404 >BLOCK Thermal Overload Pro-
tection (>BLK ThOverload)
Therm. Overload SP * * * LED BI BO 167 3 1 Yes
044.2411 Thermal Overload Protection
OFF (Th.Overload OFF)
Therm. Overload OUT ON
OFF
* * LED BO 167 11 1 Yes
044.2412 Thermal Overload Protection
BLOCKED (Th.Overload BLK)
Therm. Overload OUT ON
OFF
ON
OFF
* LED BO 167 12 1 Yes
044.2413 Thermal Overload Protection
ACTIVE (Th.Overload ACT)
Therm. Overload OUT ON
OFF
* * LED BO 167 13 1 Yes
044.2421 Thermal Overload picked up
(O/L Th. pick.up)
Therm. Overload OUT ON
OFF
* * LED BO 167 17 1 Yes
044.2451 Thermal Overload TRIP (ThOver-
load TRIP)
Therm. Overload OUT * ON
OFF
m LED BO 167 21 2 Yes
044.2491 Th. Overload Not available for
this obj. (O/L Not avail.)
Therm. Overload OUT ON * * LED BO
044.2494 Th. Overload err.:adverse
Adap.factor CT (O/L Adap.fact.)
Therm. Overload OUT ON * * LED BO
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
To Next Page
