A.9 Information List
587
7UT613/63x Manual
C53000-G1176-C160-2
044.2601 >Emergency start Th. Overload
Protection (>Emer.Start O/L)
Therm. Overload SP ON
OFF
* * LED BI BO 167 7 1 Yes
044.2602 Th. Overload Current Alarm (I
alarm) (O/L I Alarm)
Therm. Overload OUT ON
OFF
* * LED BO 167 15 1 Yes
044.2603 Thermal Overload Alarm (O/L Θ
Alarm)
Therm. Overload OUT ON
OFF
* * LED BO 167 16 1 Yes
044.2604 Thermal Overload hot spot Th.
Alarm (O/L ht.spot Al.)
Therm. Overload OUT ON
OFF
* * LED BO 167 41 1 Yes
044.2605 Thermal Overload hot spot Th.
TRIP (O/L h.spot TRIP)
Therm. Overload OUT ON
OFF
* * LED BO 167 42 2 Yes
044.2606 Thermal Overload aging rate
Alarm (O/L ag.rate Al.)
Therm. Overload OUT ON
OFF
* * LED BO 167 43 1 Yes
044.2607 Thermal Overload aging rate
TRIP (O/L ag.rt. TRIP)
Therm. Overload OUT ON
OFF
* * LED BO 167 44 1 Yes
044.2609 Th. Overload No temperature
measured (O/L No Th.meas.)
Therm. Overload OUT ON * * LED BO
047.2404 >BLOCK Breaker failure
(>BLOCK BkrFail)
Breaker Failure SP * * * LED BI BO 166 103 1 Yes
047.2411 Breaker failure is switched OFF
(BkrFail OFF)
Breaker Failure OUT ON
OFF
* * LED BO 166 151 1 Yes
047.2412 Breaker failure is BLOCKED
(BkrFail BLOCK)
Breaker Failure OUT ON
OFF
ON
OFF
* LED BO 166 152 1 Yes
047.2413 Breaker failure is ACTIVE (Bkr-
Fail ACTIVE)
Breaker Failure OUT ON
OFF
* * LED BO 166 153 1 Yes
047.2491 Breaker failure Not avail. for this
obj. (BkrFail Not av.)
Breaker Failure OUT ON * * LED BO
047.2651 >Breaker failure initiated exter-
nally (>BrkFail extSRC)
Breaker Failure SP ON
OFF
* * LED BI BO 166 104 1 Yes
047.2652 Breaker failure (internal) PICKUP
(BkrFail int PU)
Breaker Failure OUT * ON
OFF
* LED BO 166 156 2 Yes
047.2653 Breaker failure (external)
PICKUP (BkrFail ext PU)
Breaker Failure OUT * ON
OFF
* LED BO 166 157 2 Yes
047.2654 BF TRIP T1 (local trip) (BF T1-
TRIP(loc))
Breaker Failure OUT * ON m LED BO 166 192 2 Yes
047.2655 BF TRIP T2 (busbar trip) (BF T2-
TRIP(bus))
Breaker Failure OUT * ON m LED BO 166 194 2 Yes
049.2404 >BLOCK Cold-Load-Pickup
(>BLOCK CLP)
ColdLoadPickup SP * * * LED BI BO
049.2411 Cold-Load-Pickup switched OFF
(CLP OFF)
ColdLoadPickup OUT ON
OFF
* * LED BO 60 244 1 Yes
049.2412 Cold-Load-Pickup is BLOCKED
(CLP BLOCKED)
ColdLoadPickup OUT ON
OFF
ON
OFF
* LED BO 60 245 1 Yes
049.2413 Cold-Load-Pickup is RUNNING
(CLP running)
ColdLoadPickup OUT ON
OFF
* * LED BO 60 246 1 Yes
049.2505 >BLOCK Cold-Load-Pickup stop
timer (>BLK CLP stpTim)
ColdLoadPickup SP ON
OFF
ON
OFF
* LED BI BO 60 243 1 Yes
51 Device is Operational and Pro-
tecting (Device OK)
Device OUT ON
OFF
* * LED BO 135 81 1 Yes
52 At Least 1 Protection Funct. is
Active (ProtActive)
Device IntSP ON
OFF
* * LED BO 176 18 1 Yes
55 Reset Device (Reset Device) Device OUT * * * LED BO 176 4 5 No
56 Initial Start of Device (Initial Start) Device OUT ON * * LED BO 176 5 5 No
67 Resume (Resume) Device OUT ON * * LED BO 135 97 1 No
68 Clock Synchronization Error
(Clock SyncError)
Supervision OUT ON
OFF
**LEDBO
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
