A Appendix
588
7UT613/63x Manual
C53000-G1176-C160-2
69 Daylight Saving Time (DayLight-
SavTime)
Device OUT ON
OFF
**LEDBO
70 Setting calculation is running
(Settings Calc.)
Device OUT ON
OFF
* * LED BO 176 22 1 Yes
71 Settings Check (Settings Check) Device OUT * * * LED BO
72 Level-2 change (Level-2 change) Device OUT ON
OFF
**LEDBO
73 Local setting change (Local
change)
Device OUT * * * LED BO
109 Frequency out of range (Frequ.
o.o.r.)
Device OUT ON
OFF
**LEDBO
110 Event lost (Event Lost) Supervision OUT_
Ev
ON * * LED BO 135 130 1 No
113 Flag Lost (Flag Lost) Supervision OUT ON * M LED BO 135 136 1 Yes
125 Chatter ON (Chatter ON) Device OUT ON
OFF
* * LED BO 135 145 1 Yes
126 Protection ON/OFF (via system
port) (ProtON/OFF)
P.System Data 2 IntSP ON
OFF
**LEDBO
140 Error with a summary alarm
(Error Sum Alarm)
Supervision OUT * * * LED BO 176 47 1 Yes
160 Alarm Summary Event (Alarm
Sum Event)
Supervision OUT * * * LED BO 176 46 1 Yes
161 Failure: General Current Supervi-
sion (Fail I Superv.)
Measurem.Superv OUT ON
OFF
**LEDBO
163 Failure: Current Balance (Fail I
balance)
Measurem.Superv OUT ON
OFF
* * LED BO 135 183 1 Yes
164 Failure: General Voltage Supervi-
sion (Fail U Superv.)
Measurem.Superv OUT ON
OFF
**LEDBO
165 Failure: Voltage Summation
Phase-Earth (Fail Σ U Ph-E)
Measurem.Superv OUT ON
OFF
* * LED BO 135 184 1 Yes
167 Failure: Voltage Balance (Fail U
balance)
Measurem.Superv OUT ON
OFF
* * LED BO 135 186 1 Yes
169 VT Fuse Failure (alarm >10s) (VT
FuseFail>10s)
Supervision OUT ON
OFF
* * LED BO 135 188 1 Yes
170 VT Fuse Failure (alarm instanta-
neous) (VT FuseFail)
Supervision OUT ON
OFF
**LEDBO
171 Failure: Phase Sequence (Fail
Ph. Seq.)
Measurem.Superv OUT ON
OFF
**LEDBO
175 Failure: Phase Sequence Current
(Fail Ph. Seq. I)
Measurem.Superv OUT ON
OFF
* * LED BO 135 191 1 Yes
176 Failure: Phase Sequence Voltage
(Fail Ph. Seq. U)
Measurem.Superv OUT ON
OFF
* * LED BO 135 192 1 Yes
177 Failure: Battery empty (Fail Bat-
tery)
Supervision OUT ON
OFF
* * LED BO 135 193 1 Yes
181 Error: Measurement system
(Error MeasurSys)
Supervision OUT ON
OFF
* * LED BO 135 178 1 Yes
183 Error Board 1 (Error Board 1) Supervision OUT ON
OFF
* * LED BO 135 171 1 Yes
184 Error Board 2 (Error Board 2) Supervision OUT ON
OFF
* * LED BO 135 172 1 Yes
185 Error Board 3 (Error Board 3) Supervision OUT ON
OFF
* * LED BO 135 173 1 Yes
186 Error Board 4 (Error Board 4) Supervision OUT ON
OFF
* * LED BO 135 174 1 Yes
187 Error Board 5 (Error Board 5) Supervision OUT ON
OFF
* * LED BO 135 175 1 Yes
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
To Next Page
