Siemens SIPROTEC 7UT63 series User Manual

A Appendix
594
7UT613/63x Manual
C53000-G1176-C160-2
207.2541 Time Overcurrent Phase-2 I>>
Time Out (O/C Ph2 I>>TOut)
Phase O/C 2 OUT * * * LED BO
207.2542 Time Overcurrent Phase-2 I>
Time Out (O/C Ph2 I> TOut)
Phase O/C 2 OUT * * * LED BO
207.2543 Time Overcurrent Phase-2 Ip
Time Out (O/C Ph2 Ip TOut)
Phase O/C 2 OUT * * * LED BO
207.2551 Time Overcurrent Phase-2 I>>
TRIP (O/C Ph2 I>>TRIP)
Phase O/C 2 OUT * ON * LED BO
207.2552 Time Overcurrent Phase-2 I>
TRIP (O/C Ph2 I> TRIP)
Phase O/C 2 OUT * ON * LED BO
207.2553 Time Overcurrent Phase-2 Ip
TRIP (O/C Ph2 Ip TRIP)
Phase O/C 2 OUT * ON * LED BO
208.2413 Dynamic settings O/C Phase-2
are ACTIVE (I-2 Dyn.set.ACT)
ColdLoadPickup OUT ON
OFF
ON
OFF
* LED BO
209.2404 >BLOCK Phase time overcurrent
3 (>BLK Phase O/C3)
Phase O/C 3 SP * * * LED BI BO
209.2411 Time Overcurrent Phase-3 is
OFF (O/C Phase-3 OFF)
Phase O/C 3 OUT ON
OFF
**LEDBO
209.2412 Time Overcurrent Phase-3 is
BLOCKED (O/C Phase-3 BLK)
Phase O/C 3 OUT ON
OFF
ON
OFF
* LED BO
209.2413 Time Overcurrent Phase-3 is
ACTIVE (O/C Phase-3 ACT)
Phase O/C 3 OUT ON
OFF
**LEDBO
209.2422 Time Overcurrent Phase-3 L1
picked up (O/C Ph3 L1 PU)
Phase O/C 3 OUT * ON
OFF
* LED BO
209.2423 Time Overcurrent Phase-3 L2
picked up (O/C Ph3 L2 PU)
Phase O/C 3 OUT * ON
OFF
* LED BO
209.2424 Time Overcurrent Phase-3 L2
picked up (O/C Ph3 L3 PU)
Phase O/C 3 OUT * ON
OFF
* LED BO
209.2491 O/C Phase3 Not available for this
object (O/C Ph3 Not av.)
Phase O/C 3 OUT ON * * LED BO
209.2501 >BLOCK time overcurrent
Phase-3 InRush (>BLK
Ph.O/C3Inr)
Phase O/C 3 SP ON
OFF
ON
OFF
* LED BI BO
209.2502 >Time Overcurrent Phase-3
BLOCK I>> (>O/C3 BLOCK I>>)
Phase O/C 3 SP * * * LED BI BO
209.2503 >Time Overcurrent Phase-3
BLOCK I> (>O/C3 BLOCK I>)
Phase O/C 3 SP * * * LED BI BO
209.2504 >Time Overcurrent Phase-3
BLOCK Ip (>O/C3 BLOCK Ip)
Phase O/C 3 SP * * * LED BI BO
209.2514 Time Overcurrent Phase-3 I>>
BLOCKED (O/C Ph3 I>> BLK)
Phase O/C 3 OUT ON
OFF
ON
OFF
* LED BO
209.2515 Time Overcurrent Phase-3 I>
BLOCKED (O/C Ph3 I> BLK)
Phase O/C 3 OUT ON
OFF
ON
OFF
* LED BO
209.2516 Time Overcurrent Phase-2 Ip
BLOCKED (O/C Ph3 Ip BLK)
Phase O/C 3 OUT ON
OFF
ON
OFF
* LED BO
209.2521 Time Overcurrent Phase-3 I>>
picked up (O/C Ph3 I>> PU)
Phase O/C 3 OUT * ON
OFF
* LED BO
209.2522 Time Overcurrent Phase-3 I>
picked up (O/C Ph3 I> PU)
Phase O/C 3 OUT * ON
OFF
* LED BO
209.2523 Time Overcurrent Phase-3 Ip
picked up (O/C Ph3 Ip PU)
Phase O/C 3 OUT * ON
OFF
* LED BO
209.2524 Time Overcurrent Ph3 I> InRush
picked up (O/C Ph3 I> Inr)
Phase O/C 3 OUT * ON
OFF
* LED BO
209.2525 Time Overcurrent Ph3 Ip InRush
picked up (O/C Ph3 Ip Inr)
Phase O/C 3 OUT * ON
OFF
* LED BO
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
