A.11 Measured Values
619
7UT613/63x Manual
C53000-G1176-C160-2
7744 IDiffL3(I/Inominal object [%]) (IDiffL3=) Meas. Dif/Rest. - - - - - CFC CD DD
7745 IRestL1(I/Inominal object [%]) (IRestL1=) Meas. Dif/Rest. - - - - - CFC CD DD
7746 IRestL2(I/Inominal object [%]) (IRestL2=) Meas. Dif/Rest. - - - - - CFC CD DD
7747 IRestL3(I/Inominal object [%]) (IRestL3=) Meas. Dif/Rest. - - - - - CFC CD DD
30633 Phase angle of current I1 (ϕI1=) Measurement - - - - - CFC CD DD
30634 Phase angle of current I2 (ϕI2=) Measurement - - - - - CFC CD DD
30635 Phase angle of current I3 (ϕI3=) Measurement - - - - - CFC CD DD
30636 Phase angle of current I4 (ϕI4=) Measurement - - - - - CFC CD DD
30637 Phase angle of current I5 (ϕI5=) Measurement - - - - - CFC CD DD
30638 Phase angle of current I6 (ϕI6=) Measurement - - - - - CFC CD DD
30639 Phase angle of current I7 (ϕI7=) Measurement - - - - - CFC CD DD
30640 3I0 (zero sequence) of side 1 (3I0S1=) Measurement - - - - - CFC CD DD
30641 I1 (positive sequence) of side 1 (I1S1=) Measurement - - - - - CFC CD DD
30642 I2 (negative sequence) of side 1 (I2S1=) Measurement - - - - - CFC CD DD
30643 3I0 (zero sequence) of side 2 (3I0S2=) Measurement - - - - - CFC CD DD
30644 I1 (positive sequence) of side 2 (I1S2=) Measurement - - - - - CFC CD DD
30645 I2 (negative sequence) of side 2 (I2S2=) Measurement - - - - - CFC CD DD
30646 Operat. meas. current I1 (I1=) Measurement - - - - - CFC CD DD
30647 Operat. meas. current I2 (I2=) Measurement - - - - - CFC CD DD
30648 Operat. meas. current I3 (I3=) Measurement - - - - - CFC CD DD
30649 Operat. meas. current I4 (I4=) Measurement - - - - - CFC CD DD
30650 Operat. meas. current I5 (I5=) Measurement - - - - - CFC CD DD
30651 Operat. meas. current I6 (I6=) Measurement - - - - - CFC CD DD
30652 Operat. meas. current I7 (I7=) Measurement - - - - - CFC CD DD
30653 Operat. meas. current I8 (I8=) Measurement - - - - - CFC CD DD
30656 Operat. meas. voltage Umeas. (Umeas.=) Measurement - - - - - CFC CD DD
30661 Operat. meas. current IL1 meas. loc. 1
(IL1M1=)
Measurement 134 149 No 9 2 CFC CD DD
30662 Operat. meas. current IL2 meas. loc. 1
(IL2M1=)
Measurement 134 149 No 9 1 CFC CD DD
30663 Operat. meas. current IL3 meas. loc. 1
(IL3M1=)
Measurement 134 149 No 9 3 CFC CD DD
30664 3I0 (zero sequence) of meas. loc. 1 (3I0M1=) Measurement - - - - - CFC CD DD
30665 I1 (positive sequence) of meas. loc. 1
(I1M1=)
Measurement - - - - - CFC CD DD
30666 I2 (negative sequence) of meas. loc. 1
(I2M1=)
Measurement - - - - - CFC CD DD
30667 Operat. meas. current IL1 meas. loc. 2
(IL1M2=)
Measurement 134 149 No 9 5 CFC CD DD
30668 Operat. meas. current IL2 meas. loc. 2
(IL2M2=)
Measurement 134 149 No 9 4 CFC CD DD
30669 Operat. meas. current IL3 meas. loc. 2
(IL3M2=)
Measurement 134 149 No 9 6 CFC CD DD
30670 3I0 (zero sequence) of meas. loc. 2 (3I0M2=) Measurement - - - - - CFC CD DD
30671 I1 (positive sequence) of meas. loc. 2
(I1M2=)
Measurement - - - - - CFC CD DD
30672 I2 (negative sequence) of meas. loc. 2
(I2M2=)
Measurement - - - - - CFC CD DD
30673 Operat. meas. current IL1 meas. loc. 3
(IL1M3=)
Measurement 134 149 No 9 8 CFC CD DD
30674 Operat. meas. current IL2 meas. loc. 3
(IL2M3=)
Measurement 134 149 No 9 7 CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
