A Appendix
620
7UT613/63x Manual
C53000-G1176-C160-2
30675 Operat. meas. current IL3 meas. loc. 3
(IL3M3=)
Measurement 134 149 No 9 9 CFC CD DD
30676 3I0 (zero sequence) of meas. loc. 3 (3I0M3=) Measurement - - - - - CFC CD DD
30677 I1 (positive sequence) of meas. loc. 3
(I1M3=)
Measurement - - - - - CFC CD DD
30678 I2 (negative sequence) of meas. loc. 3
(I2M3=)
Measurement - - - - - CFC CD DD
30679 Operat. meas. current IL1 meas. loc. 4
(IL1M4=)
Measurement 134 149 No 9 11 CFC CD DD
30680 Operat. meas. current IL2 meas. loc. 4
(IL2M4=)
Measurement 134 149 No 9 10 CFC CD DD
30681 Operat. meas. current IL3 meas. loc. 4
(IL3M4=)
Measurement 134 149 No 9 12 CFC CD DD
30682 3I0 (zero sequence) of meas. loc. 4 (3I0M4=) Measurement - - - - - CFC CD DD
30683 I1 (positive sequence) of meas. loc. 4
(I1M4=)
Measurement - - - - - CFC CD DD
30684 I2 (negative sequence) of meas. loc. 4
(I2M4=)
Measurement - - - - - CFC CD DD
30685 Operat. meas. current IL1 meas. loc. 5
(IL1M5=)
Measurement 134 149 No 9 14 CFC CD DD
30686 Operat. meas. current IL2 meas. loc. 5
(IL2M5=)
Measurement 134 149 No 9 13 CFC CD DD
30687 Operat. meas. current IL3 meas. loc. 5
(IL3M5=)
Measurement 134 149 No 9 15 CFC CD DD
30688 3I0 (zero sequence) of meas. loc. 5 (3I0M5=) Measurement - - - - - CFC CD DD
30689 I1 (positive sequence) of meas. loc. 5
(I1M5=)
Measurement - - - - - CFC CD DD
30690 I2 (negative sequence) of meas. loc. 5
(I2M5=)
Measurement - - - - - CFC CD DD
30713 3I0 (zero sequence) of side 3 (3I0S3=) Measurement - - - - - CFC CD DD
30714 I1 (positive sequence) of side 3 (I1S3=) Measurement - - - - - CFC CD DD
30715 I2 (negative sequence) of side 3 (I2S3=) Measurement - - - - - CFC CD DD
30716 Operat. meas. current IL1 side 4 (IL1S4=) Measurement - - - - - CFC CD DD
30717 Operat. meas. current IL2 side 4 (IL2S4=) Measurement - - - - - CFC CD DD
30718 Operat. meas. current IL3 side 4 (IL3S4=) Measurement - - - - - CFC CD DD
30719 3I0 (zero sequence) of side 4 (3I0S4=) Measurement - - - - - CFC CD DD
30720 I1 (positive sequence) of side 4 (I1S4=) Measurement - - - - - CFC CD DD
30721 I2 (negative sequence) of side 4 (I2S4=) Measurement - - - - - CFC CD DD
30722 Operat. meas. current IL1 side 5 (IL1S5=) Measurement - - - - - CFC CD DD
30723 Operat. meas. current IL2 side 5 (IL2S5=) Measurement - - - - - CFC CD DD
30724 Operat. meas. current IL3 side 5 (IL3S5=) Measurement - - - - - CFC CD DD
30725 3I0 (zero sequence) of side 5 (3I0S5=) Measurement - - - - - CFC CD DD
30726 I1 (positive sequence) of side 5 (I1S5=) Measurement - - - - - CFC CD DD
30727 I2 (negative sequence) of side 5 (I2S5=) Measurement - - - - - CFC CD DD
30728 Operat. meas. auxiliary current IX1 (IX1=) Measurement - - - - - CFC CD DD
30729 Operat. meas. auxiliary current IX2 (IX2=) Measurement - - - - - CFC CD DD
30730 Operat. meas. auxiliary current IX3 (IX3=) Measurement - - - - - CFC CD DD
30731 Operat. meas. auxiliary current IX4 (IX4=) Measurement - - - - - CFC CD DD
30732 Operat. meas. current I9 (I9=) Measurement - - - - - CFC CD DD
30733 Operat. meas. current I10 (I10=) Measurement - - - - - CFC CD DD
30734 Operat. meas. current I11 (I11=) Measurement - - - - - CFC CD DD
30735 Operat. meas. current I12 (I12=) Measurement - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
