A.11 Measured Values
621
7UT613/63x Manual
C53000-G1176-C160-2
â–
30736 Phase angle in phase IL1 meas. loc. 1
(Ï•IL1M1=)
Measurement - - - - - CFC CD DD
30737 Phase angle in phase IL2 meas. loc. 1
(Ï•IL2M1=)
Measurement - - - - - CFC CD DD
30738 Phase angle in phase IL3 meas. loc. 1
(Ï•IL3M1=)
Measurement - - - - - CFC CD DD
30739 Phase angle in phase IL1 meas. loc. 2
(Ï•IL1M2=)
Measurement - - - - - CFC CD DD
30740 Phase angle in phase IL2 meas. loc. 2
(Ï•IL2M2=)
Measurement - - - - - CFC CD DD
30741 Phase angle in phase IL3 meas. loc. 2
(Ï•IL3M2=)
Measurement - - - - - CFC CD DD
30742 Phase angle in phase IL1 meas. loc. 3
(Ï•IL1M3=)
Measurement - - - - - CFC CD DD
30743 Phase angle in phase IL2 meas. loc. 3
(Ï•IL2M3=)
Measurement - - - - - CFC CD DD
30744 Phase angle in phase IL3 meas. loc. 3
(Ï•IL3M3=)
Measurement - - - - - CFC CD DD
30745 Phase angle in phase IL1 meas. loc. 4
(Ï•IL1M4=)
Measurement - - - - - CFC CD DD
30746 Phase angle in phase IL2 meas. loc. 4
(Ï•IL2M4=)
Measurement - - - - - CFC CD DD
30747 Phase angle in phase IL3 meas. loc. 4
(Ï•IL3M4=)
Measurement - - - - - CFC CD DD
30748 Phase angle in phase IL1 meas. loc. 5
(Ï•IL1M5=)
Measurement - - - - - CFC CD DD
30749 Phase angle in phase IL2 meas. loc. 5
(Ï•IL2M5=)
Measurement - - - - - CFC CD DD
30750 Phase angle in phase IL3 meas. loc. 5
(Ï•IL3M5=)
Measurement - - - - - CFC CD DD
30751 Phase angle in auxiliary current IX1 (Ï•IX1=) Measurement - - - - - CFC CD DD
30752 Phase angle in auxiliary current IX2 (Ï•IX2=) Measurement - - - - - CFC CD DD
30753 Phase angle in auxiliary current IX3 (Ï•IX3=) Measurement - - - - - CFC CD DD
30754 Phase angle in auxiliary current IX4 (Ï•IX4=) Measurement - - - - - CFC CD DD
30755 Phase angle of current I8 (Ï•I8=) Measurement - - - - - CFC CD DD
30756 Phase angle of current I9 (Ï•I9=) Measurement - - - - - CFC CD DD
30757 Phase angle of current I10 (Ï•I10=) Measurement - - - - - CFC CD DD
30758 Phase angle of current I11 (Ï•I11=) Measurement - - - - - CFC CD DD
30759 Phase angle of current I12 (Ï•I12=) Measurement - - - - - CFC CD DD
30760 Operat. meas. voltage U4 (U4 =) Measurement - - - - - CFC CD DD
30761 Operat. meas. voltage U0 measured
(U0meas.=)
Measurement - - - - - CFC CD DD
30762 Operat. meas. voltage U0 calculated
(U0calc.=)
Measurement - - - - - CFC CD DD
30792 Phase angle of voltage UL1E (Ï•UL1E=) Measurement - - - - - CFC CD DD
30793 Phase angle of voltage UL2E (Ï•UL2E=) Measurement - - - - - CFC CD DD
30794 Phase angle of voltage UL3E (Ï•UL3E=) Measurement - - - - - CFC CD DD
30795 Phase angle of voltage U4 (Ï•U4=) Measurement - - - - - CFC CD DD
30796 Phase angle of voltage UE (Ï•UE=) Measurement - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
