2.1 General
91
7UT613/63x Manual
C53000-G1176-C160-2
424 DMT/IDMT E AT no assig. poss.
AuxiliaryCT IX1
AuxiliaryCT IX2
AuxiliaryCT IX3
AuxiliaryCT IX4
AuxiliaryCT IX1 DMT / IDMT Earth assigned to
427 DMT 1PHASE AT no assig. poss.
AuxiliaryCT IX1
AuxiliaryCT IX2
AuxiliaryCT IX3
AuxiliaryCT IX4
AuxiliaryCT IX1 DMT 1Phase assigned to
430 DMT/IDMT Ph2 AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT Phase 2 assigned to
432 DMT/IDMT Ph3 AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT Phase 3 assigned to
434 DMT/IDMT3I0-2AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT 3I0 2 assigned to
436 DMT/IDMT3I0-3AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT 3I0 3 assigned to
438 DMT/IDMT E2 AT no assig. poss.
AuxiliaryCT IX1
AuxiliaryCT IX2
AuxiliaryCT IX3
AuxiliaryCT IX4
AuxiliaryCT IX1 DMT / IDMT Earth 2 assigned to
Addr. Parameter Setting Options Default Setting Comments
