Siemens SIPROTEC 7UT63 series User Manual

2 Functions
92
7UT613/63x Manual
C53000-G1176-C160-2
440 UNBAL. LOAD AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 Unbalance Load (Neg. Seq.) as-
signed to
442 THERM. O/L AT Side 1
Side 2
Side 3
Side 4
Side 5
Side 1 Thermal Overload Protection as-
signed to
444 THERM. O/L 2 AT Side 1
Side 2
Side 3
Side 4
Side 5
Side 1 Thermal Overload Protection2 as-
signed to
470 BREAKER FAIL.AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Ext. switchg. 1
Side 1 Breaker Failure Protection as-
signed to
471 BREAKER FAIL2AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Ext. switchg. 1
Side 1 Breaker Failure Protection 2 as-
signed to
511 STRPNT->OBJ M1 YES
NO
YES CT-Strpnt. Meas. Loc.1 in Dir. of
Object
512 IN-PRI CT M1 1 .. 100000 A 200 A CT Rated Primary Current Meas.
Loc. 1
513 IN-SEC CT M1 1A
5A
1A CT Rated Secondary Current
Meas. Loc. 1
521 STRPNT->OBJ M2 YES
NO
YES CT-Strpnt. Meas. Loc.2 in Dir. of
Object
522 IN-PRI CT M2 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 2
Addr. Parameter Setting Options Default Setting Comments
