2.1 General
93
7UT613/63x Manual
C53000-G1176-C160-2
523 IN-SEC CT M2 1A
5A
1A CT Rated Secondary Current
Meas. Loc. 2
531 STRPNT->OBJ M3 YES
NO
YES CT-Strpnt. Meas. Loc.3 in Dir. of
Object
532 IN-PRI CT M3 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 3
533 IN-SEC CT M3 1A
5A
1A CT Rated Secondary Current
Meas. Loc. 3
541 STRPNT->OBJ M4 YES
NO
YES CT-Strpnt. Meas. Loc.4 in Dir. of
Object
542 IN-PRI CT M4 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 4
543 IN-SEC CT M4 1A
5A
1A CT Rated Secondary Current
Meas. Loc. 4
551 STRPNT->OBJ M5 YES
NO
YES CT-Strpnt. Meas. Loc.5 in Dir. of
Object
552 IN-PRI CT M5 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 5
553 IN-SEC CT M5 1A
5A
1A CT Rated Secondary Current
Meas. Loc. 5
561 STRPNT->BUS I1 YES
NO
YES CT-Starpoint I1 in Direction of
Busbar
562 IN-PRI CT I1 1 .. 100000 A 200 A CT Rated Primary Current I1
563 IN-SEC CT I1 1A
5A
0.1A
1A CT Rated Secondary Current I1
571 STRPNT->BUS I2 YES
NO
YES CT-Starpoint I2 in Direction of
Busbar
572 IN-PRI CT I2 1 .. 100000 A 200 A CT Rated Primary Current I2
573 IN-SEC CT I2 1A
5A
0.1A
1A CT Rated Secondary Current I2
581 STRPNT->BUS I3 YES
NO
YES CT-Starpoint I3 in Direction of
Busbar
582 IN-PRI CT I3 1 .. 100000 A 200 A CT Rated Primary Current I3
583 IN-SEC CT I3 1A
5A
0.1A
1A CT Rated Secondary Current I3
591 STRPNT->BUS I4 YES
NO
YES CT-Starpoint I4 in Direction of
Busbar
592 IN-PRI CT I4 1 .. 100000 A 200 A CT Rated Primary Current I4
593 IN-SEC CT I4 1A
5A
0.1A
1A CT Rated Secondary Current I4
601 STRPNT->BUS I5 YES
NO
YES CT-Starpoint I5 in Direction of
Busbar
Addr. Parameter Setting Options Default Setting Comments
