SIRIUS 3RT2 contactors/contactor assemblies
2.5 Mounting
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
151
Table 2- 21 Replacing a magnet coil (size S0/AC)
Step Operating instruction Image
1 Use a screwdriver to lift up the retaining
clips between the rear and front halves of
the contactor.

2 Push the two halves of the contactor apart.

3 Take the magnet coil out of the front half of
the contactor.

