SIRIUS 3RT2 contactors/contactor assemblies
2.7 Accessories
SIRIUS Innovations
186 System Manual, 01/2011, A8E56203870002-03
Table 2- 40 Disassembling the mechanical latch
Step Operating instruction Image
1 Release the mechanical latch.

2 / 3 / 4 Unlock the mechanical latch and remove it
from the contactor.



