SIRIUS 3RT2 contactors/contactor assemblies
2.7 Accessories
SIRIUS Innovations
218 System Manual, 01/2011, A8E56203870002-03
Step Operating instruction Figure
6 Connect contactors Q11 and Q12 together.
Note
As there are no wiring kits for 4-pole reversing contactor assemblies, the main and control
circuits are wired using a cable.
