SIRIUS 3RV2 motor starter protectors
4.10 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
463
Up to 240 V AC Up to 400 V/415 V AC Motor starter
protector
Rated current
I
n
Icu Ics Max. fuse (gL/gG) Icu Ics Max. fuse (gL/gG)
Type A kA kA A kA kA A
Size S0
16 100 100 - 55 25 100
20 100 100 - 55 25 125
22 100 100 - 55 25 125
25 100 100 - 55 25 125
28 100 100 - 55 25 125
32 100 100 - 55 25 125
36 100 100 - 20 10 125
3RV2.2
40 100 100 - 20 10 125
Table 4- 33 Short-circuit breaking capacity I
CU
, I
CS
acc. to IEC 60947-2 - Part 2
Up to 440 V
/460 V AC Up to 500 V /525 V AC Up to 690 V AC Motor
starter
protector
Rated current
I
n
I
cu
I
cs
Max. fuse
(gL/gG)
3)
I
cu
I
cs
Max. fuse (gL/gG) I
cu
I
cs
Max.
fuse
(gL/gG)
Type A kA kA A kA kA A kA kA A
Size S00
0.16 ... 1.25 100 100 - 100 100 - 100 100 -
1.6 100 100 - 100 100 - 100 100 -
2 100 100 - 100 100 - 10 10 25
2.5 100 100 - 100 100 - 10 10 25
3.2 100 100 - 100 100 - 10 10 32
4 100 100 - 100 100 - 6 4 32
5 100 100 - 100 100 - 6 4 32
6.3 100 100 - 100 100 - 6 4 50
8 50 50 63 42 42 63 6 4 50
10 50 50 80 42 42 63 6 4 50
12.5 50 50 80 42 42 80 6 4 63
3RV2.1
16 50 10 80 10 5 80 4 4 63
Size S0
16 50 10 80 10 5 80 4 2 63
20 50 10 80 10 5 80 4 2 63
22 50 10 100 10 5 80 4 2 63
25 50 10 100 10 5 80 4 2 63
28 30 10 125 10 5 100 4 2 100
32 30 10 125 10 5 100 4 2 100
36 12 8 125 6 3 100 3 2 100
3RV2.2
40 12 8 125 6 3 100 3 2 100
