SIRIUS 3RA21/22 load feeders
6.6 Mounting
SIRIUS Innovations
592 System Manual, 01/2011, A8E56203870002-03



$&
G
Step Operating instruction
2 Attach the contactor and the link module to the bottom of the motor starter protector. Check
the guide tabs.
3 Insert the pins into the corresponding main conductor terminal.
4 Screw all connectors tight.
Table 6- 20 Main conductor terminals on the contactor (size S0)
Main conductor terminals on the contactor (a) (S0):
DDD
