System overview
1.10 Connection to the higher-level control
SIRIUS Innovations
92 System Manual, 01/2011, A8E56203870002-03
SIRIUS 4SI electronic module
Ideally suited to connecting SIRIUS Innovations products to IO-Link is the IO-Link master for
SIRIUS controls: the SIRIUS 4SI electronic module for SIMATIC ET 200S.
The SIRIUS 4SI electronic module facilitates the efficient and space-saving integration of IO-
Link-capable SIRIUS switching devices into the TIA world. It connects up to 16 SIRIUS load
feeders to the higher-level control environment.
Table 1- 37 SIRIUS 4SI electronic module
Area Customer benefits
Functions
Integration of IO-Link-capable SIRIUS
controls in the distributed I/O ET 200S.
Diagnostics data.
Status display and group fault signaling.
Dimensioning and design
Width 15 mm.
4 IO-Link ports.
Connection of up to 16 load feeders.
Mounting advantages
Considerably reduced wiring and space
requirements in the control cabinet.
Terminal modules with screw-type, spring-
loaded, and insulation displacement
connection system.
Application areas/customer benefits
Considerably lower price (50%) than the IO-
Link master if only SIRIUS devices are used.
Reduced wiring
(5 cable connections for 4 feeders).
Fast module selection via the ET 200
configurator.
