Technical data
9.1 Functional data
SIWAREX WL200
Operating Instructions, 07/2016, A5E02199611B-03
49
Variable
Value
Maximum tightening torque of the fixing screws
for E
max
= 5; 10; 20; 50; 100 kg
for E
max
= 200 kg
14 Nm
16 Nm
Cable connection Six-core, shielded
1 m
1)
Type approval to OIML for SIWAREX WL260 SP-S SA available soon
9.1.5
SIWAREX WL260 SP-S SB
Table 9- 5 Technical data SIWAREX WL260 SP-S SB
Variable
Value
Type series
WL260
Designation
SP-S SB
Construction type
Single-point load cell
Possible applications
Single-point scales, conveyor scales
Rated load E
max
6; 12; 30; 60 kg
Accuracy class according to OIML R60
C3
Max. scale interval n
LC
3000
Min. scale interval V
min
E
max
/ 15000
Combined error F
comb
≤ ± 0.02% C
n
Deviation F
V
± 0.02% C
n
Creep error F
cr
30 min
≤ ± 0.0245% C
n
Temperature coefficient
Characteristic value T
Kc
Zero signal T
Ko
0.0090% C
n
/ 10 K
0.0094% C
n
/ 10 K
Min. initial loading E
min
0 kg
Maximum working load L
u
150% E
max
Break load L
d
300% E
max
Maximum lateral load L
lq
100% E
max
Recommended supply voltage
5 to 12 V DC
Maximum supply voltage 18 V DC
Rated characteristic value C
Rated
2.0 ± 0.2 mV/V
Tolerance of zero signal D
o
< ± 1.5% C
n
Input resistance R
i
400 ± 20 Ω
Output resistance R
o
350 ± 3.5 Ω
Insulation resistance R
is
≥ 5000 MΩ at 50 V DC
Rated temperature range B
tn
- 10 to + 40 °C
Operating temperature range B
tu
- 35 to + 65 °C
Storage temperature range B
ts
- 35 to + 65 °C
