5.3 Connecting up
Signal assignment for the load cell connecting cables
Identifying colors and signal assignment for the connecting cables of load cells not listed: See
the data sheet for the appropriate load cell.
Table 5-1 Signal assignment for the load cell connecting cables
Load cell Function/color of connecting cable
EXC+ EXC- SIG+ SIG- Sense+ Sense- Shield not
connected
to the load
cell body
SIWAREX WL260
SP-S AA
Red Black Green White Blue Brown Trans‐
parent
SIWAREX WL260
SP-S AB
Red Black Green White Blue Brown Trans‐
parent
SIWAREX WL260
SP-S AE
Red Black Green White n.a. n.a. Trans‐
parent
SIWAREX WL260
SP-S CA
Red Black Blue White Brown Yellow Trans‐
parent
SIWAREX WL260
SP-S SA
Green Black White Red Blue Yellow Trans‐
parent
SIWAREX WL260
SP-S SB
Green Black White Red Yellow Blue Trans‐
parent
SIWAREX WL260
SP-S SC 10 ... 50 kg
Red Black Green White Blue Yellow Trans‐
parent
SIWAREX WL260
SP-S SC 100 ... 200 kg
Red Black Green White n.a. n.a. Trans‐
parent
SIWAREX WL250
ST-S SA
Red Black Green White n.a. n.a. Trans‐
parent
SIWAREX WL230
BB-S SA
Green Black White Red n.a. n.a. Trans‐
parent
SIWAREX WL230
SB-S SA
Green Black White Red n.a. n.a. Trans‐
parent
SIWAREX WL230
SB-S CA
Red Black Green White n.a. n.a. Trans‐
parent
SIWAREX WL270
CP-S SA
Red Black Green White n.a. n.a. Trans‐
parent
SIWAREX WL270
CP-S SB
Green Black White Red n.a. n.a. Trans‐
parent
SIWAREX WL270
CP-S SC
Green Black White Red n.a. n.a. Trans‐
parent
SIWAREX WL270
K-S CA
Red White Black Blue n.a. n.a. Trans‐
parent
Connecting
5.3 Connecting up
SIWAREX WL200
Operating Instructions, 12/2021, A5E02199611B-13 29
