10.8 SIWAREX WL250 ST-S SA
E
0
0
/
%
+
Figure 10-9 SIWAREX WL250 ST-S SA dimension drawing
Rated load Dimensions in mm
L H b B M
50 kg,
100 kg
50.8 61.0 11.7 15.1 M8
250 kg,
500 kg
50.8 61.0 18.0 21.4 M12
1 t 50.8 61.0 24.4 27.8 M12
2.5 t 76.2 99.1 24.4 27.8 M20x1.5
5.0 t 74.7 99.1 30.7 34.1 M20x1.5
10 t 112.8 177.8 42.9 46.3 M30x2
Dimension drawings
10.8 SIWAREX WL250 ST-S SA
SIWAREX WL200
Operating Instructions, 12/2021, A5E02199611B-13 79
