Technical data
9.1 Functional data
SIWAREX WL200
54 Operating Instructions, 07/2016, A5E02199611B-03
Variable
Value
Rated load E
max
100; 250; 500 kg
1; 2; 3; 5; 10 t
Accuracy class according to OIML R60
C3; C4; C5
Max. scale interval n
LC
3000; 4000; 5000
Min. scale interval V
min
For E
max
= 100; 250; 500 kg; 1; 2 t
For E
max
= 3; 5; 10 t
E
max
/ 10000; 15000; 20000
E
max
/ 10000; 15000; 18000
Combined error F
comb
± 0.015% C
n
Creep error F
cr
30 min
± 0.015% C
n
Temperature coefficient
Characteristic value T
Kc
Zero signal T
Ko
0.03 % C
n
/ 10 K
0.03 % C
n
/ 10 K
Min. initial loading E
min
0 kg
Maximum working load L
u
150 % E
max
Break load L
d
300 % E
max
Maximum lateral load L
lq
100% E
max
Rated measuring path h
n
at E
max
100 kg: 0.17 mm
250 kg: 0.15 mm
500 kg: 0.32 mm
1 t: 0.63 mm
2 t: 1.2 mm
3 t: 0.9 mm
5 t: 0.6 mm
10 t: 0.8 mm
Recommended supply voltage
5 to 12 V DC
Rated characteristic value C
Rated
3.0 ± 0.003 mV/V
1)
Tolerance of zero signal D
o
< ± 1.0% C
n
Input resistance R
i
350 ± 3.5 Ω
Output resistance R
o
350 ± 3.5 Ω
Insulation resistance R
is
5000 MΩ at 50 V DC
Rated temperature range B
tn
-10 to +40 °C
Operating temperature range B
tu
-35 to +65 °C
Storage temperature range B
ts
-40 to +80 °C
Sensor material
Steel, nickel-plated
Degree of protection according to EN 60 529
IP67
