Siemens SIWAREX WL260 Series User Manual

Technical data
9.1 Functional data
SIWAREX WL200
Operating Instructions, 07/2016, A5E02199611B-03
61
Variable
Values
Combined error F
comb
≤ ± 0.300% C
n
≤ ± 0.500 % C
n
≤ ± 5.000% C
n
Min. initial loading E
min
0 t
Hysteresis
≤ ± 0.300% C
n
≤ ± 0.500 % C
n
≤ ± 2.000% C
n
Creep error F
cr
30 min
≤ ± 0.300% C
n
≤ ± 0.400 % C
n
≤ ± 4.000% C
n
Temperature coeffi-
cient
Characteristic value
T
Kc
≤ ± 0.250% C
n
/ 5 °C ≤ ± 0.250% C
n
/ 5 °C ≤ ± 0.500% C
n
/ 5 °C
Zero signal T
Ko
≤ ± 0.250% C
n
/ 5 °C
≤ ± 0.500% C
n
/ 5 °C
≤ ± 0.500% C
n
/ 5 °C
Maximum working load
L
u
120% E
max
Break load L
d
300% E
max
Maximum lateral load
L
lq
10% E
max
Tolerance of zero
signal D
0
≤ ± 1.0% C
n
≤ ± 1.5 % C
n
≤ ± 3.0% C
n
Supply voltage
Recommended
5 ... 12 V DC
Maximum
15 V
Input resistance R
i
2.8 to 280 t
275 ± 7 Ω
275 ± 15 Ω
350 t, 500 t
450 ± 4.5 Ω
450 ± 10 Ω
Output resistance R
o
2.8 to 280 t
275 ± 0.5 Ω
275 ± 1.0 Ω
350 t, 500 t
480 ± 4.8 Ω
480 ± 10 Ω
Insulation resistance
R
is
≥ 5000 MΩ at 50 V DC
Rated temperature
range B
tn
-10 ... +150 °C
Operating temperature
range B
tu
-30 ... +180 °C -30 ... +250 °C
Storage temperature
range B
ts
-30 ... +180 °C -30 ... +250 °C
Sensor material
Steel, nickel-plated
Degree of protection
according to
EN 60 529
IP66
Cable connection:
Four-core, shielded
E
max
= 2.8 t, 6 t
6 m
E
max
= 13 t, 28 t, 60 t
15 m
E
max
= 130 t, 280 t,
350 t, 500 t
20 m
Option: Double bridge
The load cells are equipped with a second strain gauge bridge. The technical specifications
correspond to the previously mentioned options. Metrologically, there are two independent
measurement circuits that are connected to two different transmitters. Mechanically, they are
treated and installed as a load cell.
