Siemens SIWAREX WL260 Series User Manual

Technical data
9.1 Functional data
SIWAREX WL200
52 Operating Instructions, 07/2016, A5E02199611B-03
Variable
Value
Min. initial loading E
min
0 kg
Maximum working load L
u
150% E
max
Break load L
d
300% E
max
Maximum lateral load L
lq
100% E
max
Rated measuring path h
n
at E
max
for E
max
= 50; 100 kg
for E
max
= 250; 500 kg
for E
max
= 1 t
for E
max
= 2.5; 5 t
for E
max
= 10 t
0.18 mm
0.24 mm
0.37 mm
0.8 mm
0.57 mm
Recommended supply voltage
5 to 12 V DC
Rated characteristic value C
Rated
3.0 ± 0.008 mV/V
Tolerance of zero signal D
o
< ± 1.0% C
n
Input resistance R
i
430 ± 60 Ω
Output resistance R
o
350 ± 3.5 Ω
Insulation resistance R
is
5000 MΩ at 50 V DC
Rated temperature range B
tn
- 10 ... + 40 °C
Operating temperature range B
tu
- 35 ... + 65 °C
Storage temperature range B
ts
- 35 ... + 65 °C
Sensor material
Stainless steel
Degree of protection according to EN 60 529 IP67
Cable connection Four-core, shielded PU cable
6 m
9.1.8
SIWAREX WL230 BB-S SA
Table 9- 8 Technical data SIWAREX WL230 BB-S SA
Variable
Value
Type series WL230
Designation
BB-S SA
Construction type
Bending beam
Possible applications Platform scales,
overhead rail scales,
container weighers,
conveyor scales
Rated load E
max
10; 20; 50; 100; 200; 500 kg
Accuracy class according to OIML R60
C3
Max. scale interval n
LC
3000
Min. scale interval V
min
E
max
/ 15000
Combined error F
comb
≤ 0.02% C
n
