Variable Value
Maximum tightening torque of the 󹪝xing screws 35 ... 40 Nm
Cable connection Six-core, shielded PVC cable
3 m
1)
SIWAREX WL260 SP-S AB is not approved for legal-for-trade operation.
9.1.3 SIWAREX WL260 SP-S CA
Table 9-3 Technical speci󹪝cations SIWAREX WL260 SP-S CA
Variable Value
Type series WL260
Designation SP-S CA
Construction type Single-point load cell
Possible applications Platform scales and belt scales
Rated load E
max
150, 250, 500, 1000 kg
Maximum platform size 600 x 800 mm
Accuracy class according to OIML R60 C3
Max. scale interval n
LC
3000
Min. scale interval V
min
E
max
/ 10000
Combined error F
comb
±0.02% C
n
Creep error F
cr
30 min ≤ ±0.016% C
n
Temperature coe󹪟cient
Characteristic value T
Kc
Zero signal T
Ko
≤ ±0.011% C
n
/ 10 K
≤ ±0.015% C
n
/ 10 K
Min. initial loading E
min
0 kg
Maximum working load L
u
150% E
max
Break load L
d
300% E
max
Maximum lateral load L
lq
200% E
max
Rated measuring path h
n
at E
max
0.13 mm
Recommended supply voltage 5 ... 12 V DC
Maximum supply voltage 18 V DC
Rated characteristic value C
Rated
2.0 ± 0.2 mV/V
Tolerance of zero signal D
o
< ±1.5% C
n
Input resistance R
i
400 ± 20 Ω
Output resistance R
o
350 ± 3.5 Ω
Insulation resistance R
is
≥ 5000 MΩ at 50 V DC
Rated temperature range B
tn
-10 to +40 °C
Operating temperature range B
t
-35 to +65 °C
Storage temperature range B
ts
-35 to +65 °C
Sensor material Alloyed steel
