Technical data
9.1 Functional data
SIWAREX WL200
Operating Instructions, 07/2016, A5E02199611B-03
55
Variable
Value
Maximum tightening torque for the fixing bolts
for E
max
= 100; 250; 500 kg, 1 t, 2 t
for E
max
= 3; 5 t
for E
max
= 10 t
75 Nm
500 Nm
750 Nm
Cable connection
for E
max
= 100; 250; 500 kg, 1 t, 2 t
for E
max
= 3; 5; 10 t
Four-core, shielded
4 m
6 m
1)
Output is current-calibrated
9.1.10
SIWAREX WL230 SB-S SA
Table 9- 10 Technical data SIWAREX WL230 SB-S SA
Variable
Value
Type series
WL230
Designation
SB-S SA
Construction type
Shear beam
Possible applications Platform scales,
overhead rail scales,
container weighers,
conveyor scales
Rated load E
max
500 kg
1; 2; 5 t
Accuracy class according to OIML R60
C3
1)
Max. scale interval n
LC
3000
Min. scale interval V
min
for E
max
= 500 kg
for E
max
= 1; 2; 5 t
1)
E
max
/ 10000
E
max
/ 15000
Combined error F
comb
± 0.02% C
n
Deviation F
V
± 0.02% C
n
Creep error F
cr
30 min
± 0.02% C
n
Temperature coefficient
Characteristic value T
Kc
Zero signal T
Ko
0.017% C
n
/ 10 K
0.023% C
n
/ 10 K
Min. initial loading E
min
0 kg
Maximum working load L
u
150% E
max
Break load L
d
300% E
max
Maximum lateral load L
lq
100% E
max
