Variable Value
Possible applications Tension and compression applications,
suspended scales,
hybrid scales,
container scales
Rated load E
max
50; 100; 250; 500 kg
1; 2.5; 5; 10 t
Accuracy class according to OIML R60 C3
Max. scale interval n
LC
3000
Min. scale interval V
min
for E
max
= 50; 100 kg
for E
max
= 250; 500 kg; 1; 2.5 t
for E
max
= 5; 10 t
E
max
/ 7000
E
max
/ 10000
E
max
/ 12000
Combined error F
comb
± 0.02% C
n
Deviation F
V
± 0.02% C
n
Creep error F
cr
30 min 0.02% C
n
Temperature coe󹪟cient
Characteristic value T
Kc
Zero signal T
Ko
0.014% C
n
/ 10 K
0.017% C
n
/ 10 K
Min. initial loading E
min
0 kg
Maximum working load L
u
150% E
max
Break load L
d
300% E
max
Maximum lateral load L
lq
100% E
max
Rated measuring path h
n
For E
max
= 50; 100 kg:
For E
max
= 250; 500 kg:
For E
max
= 1 t:
For E
max
= 2.5; 5 t:
For E
max
= 10 t:
0.18 mm
0.24 mm
0.37 mm
0.8 mm
0.57 mm
Recommended supply voltage 5 to 12 V DC
Rated characteristic value C
Rated
3.0 ± 0.008 mV/V
Tolerance of zero signal D
o
< ± 1.0% C
n
Input resistance R
i
430 ± 60 Ω
Output resistance R
o
350 ± 3.5 Ω
Insulation resistance R
is
5000 MΩ at 50 V DC
Rated temperature range B
tn
- 10 ... + 40 °C
Operating temperature range B
tu
- 35 ... + 65 °C
Storage temperature range B
ts
- 35 ... + 65 °C
Sensor material Stainless steel, mat. no. 1.4542
Degree of protection according to EN 60 529 IP67
Cable connection Four-core, shielded PU cable
6 m
Technical data
9.1 Functional data
