Dimension drawing for SIWAREX WL280 RN-S SA load cell for 28 t and 60 t
$
)
*
+
%
&
'
(

5
0

r
Figure 10-23 Dimension drawing for SIWAREX WL280 RN-S SA, rated load 28 t and 60 t
Rated load ∅ A in mm B in mm ∅ C in mm E in mm
28 t 120 46 35,9 25
60 t 140 62 47,9 34
Dimension drawings
10.16 SIWAREX WL280 RN-S SA
