05.2006 Connecting-up
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES Operating Instructions 7-5
Line voltage 3 AC 380 V to 480 V
Order No. Rated input Line side
Line reactor
Motor side
current cross-section Recommended fuse cross-section
6SE70... VDE AWG gR (SITOR) gL lvhrc North America VDE AWG
[A] [mm²] [A] 3NE [A] 3NA Type [V] [A] 4EP.. [mm²]
16-1EA61 6.1 1.5 16 − − − − 10 3803 AJT, LPJ 600 8
3200-
1US00
1.5 16
18-0EA61 8.0 1.5 16 − − − − 16 3805 AJT, LPJ 600 12
3400-
2US00
1.5 16
21-0EA61 10.2 2.5 14 − − − − 16 3805 AJT, LPJ 600 15
3400-
1US00
1.5 16
21-3EB61 13.2 2.5 14 25 1815-0 25 3810 AJT, LPJ 600 17.5
3500-
0US00
2.5 14
21-8EB61 17.5 4 10 25 1815-0 25 3810 AJT, LPJ 600 25
3600-
4US00
2.5 14
22-6EC61 25.5 10 6 35 1803-0 35 3814 AJT, LPJ 600 35
3600-
5US00
10 6
23-4EC61 34 16 4 40 1802-0 50 3820 AJT, LPJ 600 45
3700-
2US00
10 6
23-8ED61 37.5 16 4 63 1818-0 63 3822 AJT, LPJ 600 50
3700-
5US00
16 4
24-7ED61 47 25 2 63 1818-0 63 3822 AJT, LPJ 600 60
3800-
2US00
16 4
26-0ED61 59 25 2 80 1820-0 100 3830 AJT, LPJ 600 80
3800-
7US00
16 4
27-2ED61 72 50 00 80 1820-0 100 3830 AJT, LPJ 600 90
3900-
2US00
25 2
