Parameterizing Steps 05.2006
6SE7087-2JD60 Siemens AG
9-42 Operating Instructions SIMOVERT MASTERDRIVES
9.3 Motor list
Input in
P097
Motor order
number
(MPRD)
Rated
speed
n
n
[rpm]
Frequency
f
n
[Hz]
Current
I
n
[A]
Voltage
U
n
[V]
Torque
M
n
[Nm]
cos ϕ i
µ
[%]
1 1PH7101-2_F_ 1750 60.0 9.7 398 23.5 0.748 58.3
2 1PH7103-2_D_ 1150 40.6 9.7 391 35.7 0.809 51.8
3 1PH7103-2_F_ 1750 60.95 12.8 398 34 0.835 41.3
4 1PH7103-2_G_ 2300 78.8 16.3 388 31 0.791 50.4
5 1PH7105-2_F_ 1750 60.0 17.2 398 43.7 0.773 54.1
6 1PH7107-2_D_ 1150 40.3 17.1 360 59.8 0.807 51.4
7 1PH7107-2_F 1750 60.3 21.7 381 54.6 0.802 48.8
8 1PH7131-2_F_ 1750 59.65 23.7 398 71 0.883 34.2
9 1PH7133-2_D_ 1150 39.7 27.5 381 112 0.853 46.2
10 1PH7133-2_F_ 1750 59.65 33.1 398 95.5 0.854 41.1
11 1PH7133-2_G_ 2300 78.0 42.4 398 93 0.858 40.4
12 1PH7135-2_F_ 1750 59.45 40.1 398 117 0.862 40.3
13 1PH7137-2_D_ 1150 39.6 40.6 367 162 0.855 45.8
14 1PH7137-2_F_ 1750 59.5 53.1 357 136 0.848 43.0
15 1PH7137-2_G_ 2300 77.8 54.1 398 120 0.866 39.3
16 1PH7163-2_B_ 400 14.3 28.2 274 227 0.877 40.4
17 1PH7163-2_D_ 1150 39.15 52.2 364 208 0.841 48.7
18 1PH7163-2_F_ 1750 59.2 69.0 364 185 0.855 41.2
19 1PH7163-2_G_ 2300 77.3 78.5 398 158 0.781 55.3
20 1PH7167-2_B_ 400 14.3 35.6 294 310 0.881 39.0
21 1PH7167-2_D_ 1150 39.1 66.4 357 257 0.831 50.9
22 1PH7167-2_F_ 1750 59.15 75.2 398 224 0.860 40.3
23 1PH7184-2_B_ 400 14.2 49.5 271 390 0.840 52.5
24 1PH7184-2_D_ 1150 39.1 87.5 383 366 0.820 48.0
25 1PH7184-2_F_ 1750 59.0 120.0 388 327 0.780 52.9
26 1PH7184-2_L_ 2900 97.4 158.0 395 267 0.800 48.7
27 1PH7186-2_B_ 400 14.0 67.0 268 505 0.810 58.3
28 1PH7186-2_D_ 1150 39.0 116.0 390 482 0.800 50.4
29 1PH7186-2_F_ 1750 59.0 169.0 385 465 0.800 50.0
30 1PH7186-2_L_ 2900 97.3 206.0 385 333 0.780 52.0
31 1PH7224-2_B_ 400 14.0 88.0 268 725 0.870 41.5
32 1PH7224-2_D_ 1150 38.9 160.0 385 670 0.810 49.4
33 1PH7224-2_U_ 1750 58.9 203.0 395 600 0.840 43.4
Asynchronous
motors 1PH7(=PA6) /
1PL6 / 1PH4
