05.2006 Parameterizing Steps
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES Operating Instructions 9-43
Input in
P097
Motor order
number
(MPRD)
Rated
speed
n
n
[rpm]
Frequency
f
n
[Hz]
Current
I
n
[A]
Voltage
U
n
[V]
Torque
M
n
[Nm]
cos ϕ i
µ
[%]
34 1PH7224-2_L_ 2900 97.3 274.0 395 490 0.840 42.0
35 1PH7226-2_B_ 400 14.0 114.0 264 935 0.860 43.4
36 1PH7226-2_D_ 1150 38.9 197.0 390 870 0.840 44.4
37 1PH7226-2_F_ 1750 58.9 254.0 395 737 0.820 47.4
38 1PH7226-2_L_ 2900 97.2 348.0 390 610 0.830 44.4
39 1PH7228-2_B_ 400 13.9 136.0 272 1145 0.850 45.2
40 1PH7228-2_D_ 1150 38.9 238.0 390 1070 0.850 41.4
41 1PH7228-2_F_ 1750 58.8 342.0 395 975 0.810 49.6
42 1PH7228-2_L_ 2900 97.2 402.0 395 708 0.820 46.4
43 1PL6184-4_B_ 400 14.4 69.0 300 585 0.860 47.8
44 1PL6184-4_D_ 1150 39.4 121.0 400 540 0.860 46.3
45 1PL6184-4_F_ 1750 59.3 166.0 400 486 0.840 41.0
46 1PL6184-4_L_ 2900 97.6 209.0 400 372 0.850 37.8
47 1PL6186-4_B_ 400 14.3 90.0 290 752 0.850 52.2
48 1PL6186-4_D_ 1150 39.4 158.0 400 706 0.860 39.3
49 1PL6186-4_F_ 1750 59.3 231.0 400 682 0.840 39.8
50 1PL6186-4_L_ 2900 97.5 280.0 390 494 0.840 38.7
51 1PL6224-4_B_ 400 14.2 117.0 300 1074 0.870 38.5
52 1PL6224-4_D_ 1150 39.1 218.0 400 997 0.850 39.5
53 1PL6224-4_F_ 1750 59.2 292.0 400 900 0.870 30.8
54 1PL6224-4_L_ 2900 97.5 365.0 400 675 0.870 32.3
55 1PL6226-4_B_ 400 14.0 145.0 305 1361 0.850 46.2
56 1PL6226-4_D_ 1150 39.2 275.0 400 1287 0.870 33.5
57 1PL6226-4_F_ 1750 59.1 355.0 400 1091 0.870 34.4
58 1PL6226-4_L_ 2900 97.4 470.0 395 889 0.870 32.4
59 1PL6228-4_B_ 400 14.0 181.0 305 1719 0.860 42.5
60 1PL6228-4_D_ 1150 39.2 334.0 400 1578 0.880 30.5
61 1PL6228-4_F_ 1750 59.0 470.0 400 1448 0.860 36.8
62 1PL6228-4_L_ 2900 97.3 530.0 400 988 0.870 35.0
63 1PH4103-4_F_ 1750 61.2 20.5 400 48 0.75 56.1
64 1PH4105-4_F_ 1750 61.3 28.0 400 70 0.78 48.2
65 1PH4107-4_F_ 1750 61.0 36.0 400 89 0.78 50.0
66 1PH4133-4_F_ 1750 60.2 36.0 400 96 0.82 33.3
67 1PH4135-4_F_ 1750 59.8 52.0 400 139 0.79 42.3
68 1PH4137-4_F_ 1750 59.9 63.0 400 172 0.81 36.5
69 1PH4163-4_F_ 1750 59.3 88.0 400 235 0.78 47.7
70 1PH4167-4_F_ 1750 59.4 107.0 400 295 0.80 41.1
