Siemens Vector Control User Manual

Connecting-up 05.2006
6SE7087-2JD60 Siemens AG
7-14 Operating Instructions SIMOVERT MASTERDRIVES
S1
S2
S3/3,4
S3/1,2
S4/1,2,3
S4/4,5,6
X103
X102
X101
X108
Fig. 7-5 View of the CUVC
Switches have been changed on CUVCs from 11/2005:
♦ S1, S2, S3: Slide switch design
For contact assignment refer to section "Switch settings for slide
switch design"
♦ Switches S4 or
S41 and S42 are fitted. The contact assignment
differs depending on the switch design (see section "Switch
settings").
NOTE
