05.2006 Connecting-up
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES Operating Instructions 7-21
The following table shows how the existing line voltage is assigned for
adjustment by the fan transformer.
Rated input voltage
3 AC 200 V (- 15 %)
to 230 V (+ 15 %)
3 AC 380 V (- 15 %)
to 480 V (+ 10 %)
3 AC 500 V (- 15 %)
to 600 V (+ 10 %)
3 AC 660 V (- 15 %)
to 690 V (+ 15 %)
Supply
voltage
Transformer tappings
3 AC 170 V 200 V
3 AC 200 V 200 V
3 AC 220 V 220 V
3 AC 230 V 230 V
3 AC 264 V 230 V
3 AC 325 V 380 V
3 AC 380 V 380 V
3 AC 400 V 400 V
3 AC 415 V 400 V
3 AC 425 V 400 V 500 V
3 AC 440 V 440 V 500 V
3 AC 460 V 460 V 500 V
3 AC 480 V 460 V 500 V
3 AC 500 V 460 V 500 V
3 AC 525 V 460 V 525 V
3 AC 575 V 575 V 660 V
3 AC 600 V 575 V 660 V
3 AC 660 V 575 V 660 V
3 AC 690 V 690 V
3 AC 790 V 690 V
Table 7-10 Connecting the fan transformer
Connecting the fan
transformer
