Siemens Vector Control User Manual

Parameterization 05.2006
6SE7087-2JD60 Siemens AG
8-2 Operating Instructions SIMOVERT MASTERDRIVES
General parameters
Terminals
Communication
Control and status words
Setpoint channel
Motor/encoder
Control/gating unit
Sequence control
Diagnostics
Functions
Releases
Free blocks
Technology
SCom1/SCom2
Field bus interfaces
SIMOLINK
SCB/SCI
Motor data
Encoder data
Position control
Speed control
Current control
V/f open-loop control
Gating unit
Faults/alarms
Messages/displays
Trace
Synchronism
Positioning
Setting up/MDI
User parameters
Parameter menu
Fixed settings
Quick
parameterization
Board
configuration
Drive setting
Download
Upread/free access
Power section
definition
Menu level 1
Select via
P60 Menu Select
Menu level 2
(only on OP1S)
Menu level 3
(only on OP1S)
P358 Key P359 Lock
P60
By entering a password in P359,
access to the menus in the gray
shaded area can be prohibited to
unauthorized persons
1)
1)
1)
1)
1)
only MASTERDRIVES Motion Control
Basic positioner 1)
Fig. 8-1 Parameter menus
