Siemens Vector Control User Manual

Parameterizing Steps 05.2006
6SE7087-2JD60 Siemens AG
9-8 Operating Instructions SIMOVERT MASTERDRIVES
Use of binectors for digital inputs in factory settings:
When B0010 to B0017 (DigIn1 to 4) are used, the corresponding digital
outputs cannot be used!
P366 0 0 1 1 2 2 3 3 4 4
BICO data
set
1 2 1 2 1 2 1 2 1 2
B0010 P567 P567
B0012 P590 P590 P590 P590
B0014 P590 P590 P590 P590
B0016 P580 P580 P580 P580 P580
B0018 P567 P567 P575 P575 P575 P575 P575 P575
B0020 P555 P555 P588 P588 P588 P588 P588 P588
B0022 P554 P554 P554 P554
Meaning of the parameters in the factory setting:
Entry Description See function diagram
(in Compendium)
P554 Src ON/OFF1 -180-
P555 Src1 OFF2(electr) -180-
P567 Src3 Fault Reset -180-
P575 Src No ExtFault1 -180-
P580 Src FixSetp Bit0 -190-
P588 Src No Ext Warn 1 -190-
P590 Src BICO DSet -190-
