05.2006 Parameterizing Steps
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES Operating Instructions 9-17
Type 1PH610 1PH613 1PH616 1PH618 1PH620 1PH622
T1 in s 1500 1800 2100 2400 2400 2400
Exceptions: 1PH610 at n = 1150 rpm: T1 = 1200 n
Shaft height 100 132 160 180 225
T1 in s 1500 1800 2100 2400 2400
Type 1PH7284 1PH7286 1PH7288
T1 in s 4500 5000 5400
Shaft height 180 225
T1 in s 1800 1800
Type 1PL6284 1PH6286 1PH6288
T1 in s 3200 3900 4300
Shaft height 100 132 160
T1 in s 1500 1800 2100
If 1PH7, 1PL6, or 1PH4 motors are parameterized in the list selection
(P097), both the motor cooling (P382) and the thermal motor time
constant (P383) are assigned the correct default values.
1LG6 motors
Type 2-
pole
4-
pole
6-
pole
8-
pole
183 1800 1800 - -
186 - 1800 2700 2100
206 1800 - 2700 -
207 1800 2700 2700 2700
220 - 2400 - 2700
223 2400 2700 3300 2400
253 2700 3000 2700 3000
280 2400 3300 3000 3600
283 2400 3000 3600 3900
310 2700 3300 3600 3900
313 2700 3900 3600 4200
316 2700 3900 4200 4200
317 2700 3900 4500 3900
318 3600 3900 4500 5700
1PH6 motors
1PA6 motors
(= 1PH7 motors)
1PL6 motors
1PH4 motors
