05.2006 Control Word and Status Word
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES Operating Instructions 10-5
Bit 10: Control from the PLC command (H "control from the PLC")
HIGH signal; the process data PZD (control word, setpoints) are only
evaluated if the command has been accepted; this data is sent via the
SST1 interface of the CU, the CB/TB interface (option) and the
SST/SCB interface (option).
If several interfaces are used, only the process data of the interfaces
are evaluated, which send an H signal.
For an L signal, the last values are received in the appropriate dual
port RAM of the interface.
An H signal appears in the visualization parameter r550 "control word
1", if one of the interfaces sends an H signal!
Bit 11: Clockwise rotating field command (H "clockwise rotating field")
HIGH signal
The setpoint is influenced in conjunction with bit 12 "counter-
clockwise rotating field".
Bit 12: Counter-clockwise rotating field command (H "counter-clockwise rotating field")
HIGH signal
The setpoint is influenced in conjunction with bit 11 "clockwise-
rotating field".
The counter-clockwise rotating field and the clockwise rotating
field command have no influence on supplementary setpoint 2, which
is added after the ramp-function generator (RFG)!
Bit 13: Command to raise the motorized potentiometer (H "raise motorized
potentiometer")
HIGH signal
The motorized potentiometer in the setpoint channel is driven in
conjunction with bit 14 "motorized potentiometer, lower".
Bit 14: Command to lower the motorized potentiometer (H "lower motorized
potentiometer")
HIGH signal
The motorized potentiometer in the setpoint channel is driven in
conjunction with bit 13 "raise motorized potentiometer".
Bit 15: Command external fault 1 (L "External fault 1")
LOW signal
FAULT (007) and fault message (F035).
The inverter pulses are inhibited, the main contactor/bypass
contactor, if used, is opened.
Condition
Result
NOTE
Condition
Result
Condition
Result
NOTE
Condition
Result
Condition
Result
Condition
Result
