05.2006 Technical Data
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES Operating Instructions 13-5
Designation Value
Order No. 6SE70... 21-1CA60 21-3CA60 21-8CB60 22-3CB60 23-2CB60 24-4CC60
Rated voltage [V]
• Input
• Output
3 AC 200 (- 10 %) to 230 (+ 15 %)
3 AC 0 up to rated input voltage
Rated frequency [Hz]
• Input
• Output: V/f = constant
V = constant
50 / 60 ± 6 %
0 to 600
8 to 300
Rated current [A]
• Input
• Output
11.7
10.6
14.6
13.3
19.5
17.7
25.2
22.9
35.4
32.2
48.6
44.2
DC link voltage [V] 270 (- 10 %) to 310 (+ 15 %)
Rated output [kVA] 3.7 to 4.2 4.7 to 5.2 6.0 to 6.9 8.0 to 9.1 11.2 to 12.8 15.4 to 17.6
Auxiliary current supply [V] DC 24 (20 - 30)
• Max. aux. curr. requirement[A]
Standard version at 20 V
1.5
• Max. aux. curr. requirement[A]
Maximum version at 20 V
2.5
Pulse frequency [kHz] 1.5 to 16 (see Fig. „Derating curves“)
Load class II to EN 60 146-1-1
Base load current [A] 0.91 x rated output current
Base load duration [s] 240
Overload current [A] 1.36 x rated output current
Overload duration [s] 60
Load class II to EN 60 146-1-1 (additional)
Base load current [A] 0.91 x rated output current
Base load duration [s] 270
Overload current [A] 1.6 x rated output current
Overload duration [s] 30
Losses, cooling, power factor
Power factor
• Line cosϕ1L
• Converter cosϕC
≥ 0.98
< 0.92 ind.
Efficiency η (rated operation) ≥ 0.97
Power loss (at 2.5 kHz) [kW] 0.13 0.16 0.20 0.25 0.32 0.41
Cooling-air requirement [m³/s] 0.009 0.009 0.022 0.022 0.022 0.028
Pressure drop ∆p [Pa] 10 10 32 32 32 30
Sound pressure levels, types of construction, dimensions, weights
Sound pressure level [dB(A)] 60 60 60 60 60 60
Type of construction A A B B B C
Dimensions [mm]
• Width
• Height
• Depth
90
425
350
90
425
350
135
425
350
135
425
350
135
425
350
180
600
350
Weight approx. [kg] 8.5 8.5 12.5 12.5 12.5 21
Table 13-3 Air-cooled converter (part 1)
