05.2006 Technical Data
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES Operating Instructions 13-7
Designation Value
Order No. 6SE70... 16-1EA61 18-0EA61 21-0EA61 21-3EB61 21-8EB61 22-6EC61
Rated voltage [V]
• Input
• Output
3 AC 380 (- 15 %) to 480 (+ 10 %)
3 AC 0 up to rated input voltage
Rated frequency [Hz]
• Input
• Output: V/f = constant
V = constant
50 / 60 ± 6 %
0 to 600
8 to 300
Rated current [A]
• Input
• Output
6.7
6.1
8.8
8.0
11.2
10.2
14.5
13.2
19.3
17.5
28.1
25.5
DC link voltage [V] 510 (- 15 %) to 650 (+ 10 %)
Rated output [kVA] 4.1 to 5.0 5.3 to 6.6 6.8 to 8.4 8.7 to 10.9 11.6 to 14.5 16.8 to 21.2
Auxiliary current supply [V] DC 24 (20 - 30)
• Max. aux. curr. requirement[A]
Standard version at 20 V
1.5
• Max. aux. curr. requirement[A]
Maximum version at 20 V
2.5
Pulse frequency [kHz] 1.5 to 16 (see Fig. „Derating curves“)
Load class II to EN 60 146-1-1
Base load current [A] 0.91 x rated output current
Base load duration [s] 240
Overload current [A] 1.36 x rated output current
Overload duration [s] 60
Load class II to EN 60 146-1-1 (additional)
Base load current [A] 0.91 x rated output current
Base load duration [s] 270
Overload current [A] 1.6 x rated output current
Overload duration [s] 30
Losses, cooling, power factor
Power factor
• Line cosϕ1L
• Converter cosϕC
≥ 0.98
< 0.92 ind.
Efficiency η (rated operation) ≥ 0.97 ≥ 0.98
Power loss (at 2.5 kHz) [kW] 0.11 0.12 0.16 0.16 0.24 0.36
Cooling-air requirement [m³/s] 0.009 0.009 0.009 0.022 0.022 0.028
Pressure drop ∆p [Pa] 10 10 10 32 32 30
Sound pressure levels, types of construction, dimensions, weights
Sound pressure level [dB(A)] 60 60 60 60 60 60
Type of construction A A A B B C
Dimensions [mm]
• Width
• Height
• Depth
90
425
350
90
425
350
90
425
350
135
425
350
135
425
350
180
600
350
Weight approx. [kg] 8.5 8.5 8.5 12.5 12.5 21
Table 13-5 Air-cooled converter (part 3)
