Siemens XC1005-A User Manual

Overview
19
Building Technologies A6V10257473_e_en_--
Fire Safety 2015-03-04
Indicators
State Description
N° Color
14 Yellow Fixed – Manual release is blocked or being tested
15 Yellow Fixed – Standard = not used
– Alternative = automatic and manual release granted (UK)
16 Yellow Fixed – Automatic release is blocked
– At least one detection zone which starts the extinguishing is off or being tested
17 Red Fixed – All detection zones which start the extinguishing are in alarm condition
– One of the electrical manual triggering device (DM1103-L) is actuated
Fast One of the detection zones which start the extinguishing is in alarm condition
18 Red Fixed Extinguishing agent is released
Slow / Fast Discharged contact is not activated within 30 seconds after actuators control (according to programming)
19 Yellow Fixed Sounders are disabled
Slow Sounders test is in progress (real activation)
Fast At least, an output programmed as Sounders is in fault condition (break or short-circuit)
20 Yellow Fixed Actuators are disabled
Slow Actuators test is in progress (simulated activation)
Fast – At least, one output programmed as actuators is in fault condition (break or short-circuit)
– Calibration in progress or error or no calibration data
21 Yellow Fixed Fire controls are disabled
Slow Warning panels test is in progress (real activation)
Fast At least, one output programmed as fire controls is in fault condition (break or short-circuit)
22 Yellow Fixed RT-fault is disabled
Slow RT-fault test is in progress (real activation)
23 Yellow Fixed RT-alarm is disabled
Slow RT-alarm test is in progress (real activation)
Fast At least, one output programmed as RT-alarm is in fault condition (break or short-circuit)
24 Yellow Fixed Emergency abort is activated
Slow Emergency hold is activated (DM1103-S)
Fast At least, one input programmed as emergency hold/abort is in fault condition (break or short-circuit)
25 Red Fixed Detection zone 1 is in alarm condition
Slow Detection zone 1 is in alarm condition (first alarm)
26 Yellow Fixed / Slow Detection zone 1 is disabled (fixed) / being tested (slow)
Fast Detection zone 1 is in fault condition (break or short-circuit)
27 Red Fixed Detection zone 2 is in alarm condition
Slow Detection zone 2 is in alarm condition (first alarm)
28 Yellow Fixed / Slow Detection zone 2 is disabled (fixed) / being tested (slow)
Fast Detection zone 2 is in fault condition (break or short-circuit)
29 Red Fixed Detection zone 3 is in alarm condition
Slow Detection zone 3 is in alarm condition (first alarm)
30 Yellow Fixed / Slow Detection zone 3 is disabled (fixed) / being tested (slow)
Fast Detection zone 3 is in fault condition (break or short-circuit)
31 Red Fixed Manual release is activated (DM1103-L line)
Slow Manual release is activated (DM1103-L line) – First alarm
32 Yellow Fixed / Slow Manual release is disabled (fixed) / being tested (slow)
Fast Manual release is in fault condition (break or short-circuit)
