Maintenance
80
Building Technologies A6V10257473_e_en_--
Fire Safety 2015-03-04
Inform the person in charge of the building security about the type of
maintenance operation planned and the duration.
Switch the mechanical blocking device to the position "Blocked" (if existing).
Switch the XC10 to the "Test mode" (Z1 to Z4).
Disconnect the actuator electrical line by removing the connector from the BORA
box (or equivalent).
3.2
–
Inspection of the XC10
Check the accessibility of the control panel.
Check the good condition of XC10 housing, main-board and batteries.
Clean outside and inside the housing if necessary with a soft soap or an vacuum
cleaner. Do not use any aggressive solvent or containing abrasive material.
Check the fixation of the metallic chassis to the wall and retighten the screws if
necessary.
Check the connectors screws and retighten the screws if necessary.
Check accuracy and lisibility of the paper stripes (zone labeling …).
Upload the XC10 event memory in your PC and check for any abnormal event
recording
3.3
–
Inspection of the installation
Check the earth connection between the metallic chassis and the building
ground.
Check the battery voltage level.
Turn off the mains power supply and check the intensity of the current delivered
from the batteries. Ensure that the autonomy calculated correspond the the
battery capacity.
Check all the componants of the installation: detectors, souders, warning panels,
valve, cylinders, nozzle, pipe, over-pressure flaps …
Check the pressure of all cylinders taking into account the temperature room.
Plan the replacement of the cylinders if the pressure is too low.
Check that warning panels and electrical manual release buttons are visible.
3.4
–
Inspection of t
he functioning
Check that all leds and buzzer are activated with the "Led test".
Switch the XC10 to the "Test" mode (Z1 .. Z4) and activate detectors one by one.
For each of them, verify the zone text on XC10 operating unit and the good
operating of alarm indicators. Reset the XC10.
Disconnect each monitored output and input. For each of them, check the fault
indication displayed on the XC10 operating unit.
Operate manually the shutoff valve, the selector valves and all over-pressure
flaps (if existing) to verify the good operating. Check correct indication on the
front of the XC10 operating unit and on the warning panels (if existing).
Disconnect a manometer or a weighing device and check the indication on the
XC10 operating unit
Check with the person in charge of the building security the procedure for testing
the fire controls (shutoff air conditioning, dampers, doors …). If any disturbance
may be feared, on customer request, some tests may be simulated by
disconnecting the end equipment.
Switch Zone 1 and Zone 2 to alam condition. Check indications on the XC10
operating unit. Ensure that detectors are programmed with the right set of
