P003948 Uscan User Manual Page | 37
6. CONNECTIVITY AND ACCESSORIES
Accessories
The following accessories are supported by Uscan:
Wireless printer
Wireless bar code scanner
Signostics mobile stand (P004013)
Signostics Power Supply (P003198)
System connectivity
Warning
The user must not touch the any device connectors while in physical contact with the patient.
The Uscan probe is connected to an Android display running Signostics software to configure a
medical system. The Android display must be certified to the respective IEC standards and particular
national deviations (IEC 60950 or IEC 60601-1:2nd and/or 3rd edition).
Do not connect the Uscan display to external computers or peripherals using the USB port unless the
system is outside the patient area. Failure to comply with these guidelines may result in electric shock.
Mounting the Uscan display on a mobile stand is configuring a medical system. Only use the
Signostics provided mobile stand accessory (P004013).
Only connect accessories or items that are specified as being compatible with Uscan. Contact
Signostics
customer support or your Signostics distributor for information on compatible accessories
and systems.
When using the optional Signostics mobile stand, if a Multiple Socket Outlet is required only use an
outlet and power cable certified to IEC 60601-1, and fix to the stand using a bolt and tool.
Power sources
During operation, Uscan is electrically powered by an internal battery. The battery can be recharged by a
mains-powered supply via the provided power supplies (chargers).
Internal battery
The Uscan displays and the Uscan probe contain internal batteries.
When powered by a fully charged battery, Uscan will run for more than 12 hours with an average operating
regime of 4 x 1 minute scans per hour.
From a fully discharged state, while Uscan is in sleep mode, the battery recharges to 80% capacity when
connected to a display power supply (charger) for 3 hours.
Power Supplies (Charger)
Warning
Recharge Uscan only with the power supplies (chargers) provided.
If required, recharge the Uscan Probe only with the Signostics power supply (charger) provided
(P003198).
The Uscan power supplies are dedicated units to be used exclusively with the Uscan System only.
Do not open or modify the Signostics Power Supply P003198 or any other supplied power supplies -
Risk of electric shock
