Electromagnetic compatibility (EMC)
Caution
 Uscan contains sensitive components and circuits. Failure to observe proper static control procedures
may result in damage to the system. Any faults should be reported to Signostics
or your Uscan
distributor for repair.
Warning
 Uscan complies with the Electromagnetic Compatibility requirements of AS/NZ CISPR 11:2004 and
IEC 60601-1-2:2007. However, electronic and mobile communications equipment may transmit
electromagnetic energy through air and there is no guarantee that interference will not occur in a
particular installation or environment. Interference may result in artifacts, distortion, or degradation of
the ultrasound image. If Uscan is found to cause or respond to interference, try re-orienting Uscan or
the affected device, or increasing the separation distance between the devices. Contact Signostics
customer support or your Signostics distributor for further information.
The Uscan is intended for use in the electromagnetic environment specified below. The user of the Uscan
should assure that it is used in such an environment.
Table 8.1 Guidance and manufacturer's declaration: electromagnetic emissions
Emissions test Compliance Electromagnetic environment: guidance
RF emissions
CISPR 11
Group 1 Uscan uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
RF emissions
CISPR 11
Class A Uscan i
s suitable for use in all establishments other than domestic and those directly
connected to the public low-voltage power supply network that supplies buildings used for
domestic purposes.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations/
flicker emissions
IEC 61000-3-3
Complies
1
Uscan has Class A compliance in meaning it is suitable for use in all establishments other than domestic and those directly connected to the
public low-voltage power supply network that supplies buildings used for domestic purposes. If Uscan is found to cause or respond to
interference follow the guidelines in the warning section above
Table 8.2 Guidance and manufacturer's declaration: electromagnetic immunity
The user should assure the Uscan is used in the electromagnetic environment specified below.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment: guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8kV air
±6 kV contact ±8kV air Floors should be wood, concrete or ceramic tile. If floors
are covered with synthetic material, the relative humidity
should be at least 30%.
Electrical fast
tra
nsient/burst
IEC 61000-4-4
±2 kV for power supply
lines
±2 kV for power supply
lines
Mains power quality should be that of a typical
commercial or hospital environment.
Surge
IEC 61000-4-5
± 1kV line(s) to line(s)
± 2kV line(s) to earth
± 1kV differential mode
± 2kV common mode
Mains power quality should be that of a typical
commercial or hospital environment.
Voltage dips, short
interruptions and
voltage variations on
power supply input
li
nes
IEC 61000-4-11
<5% U
T
1
(>95% dip in
U
T
) for 0.5 cycle
40% U
T
(60% dip in
U
T
) for 5 cycles
70% U
T
(30% dip in U
T
for 25 cycles
<5% U
T
(>95% dip in
U
T
) for 5 sec
<5% U
T
1
(>95% dip in
U
T
) for 0.5 cycle
40% U
T
(60% dip in
U
T
) for 5 cycles
70% U
T
(30% dip in U
T
for 25 cycles
<5% U
T
(>95% dip in
U
T
) for 5 sec
Mains power quality should be that of a typical
commercial or hospital environment.
