P003948 Uscan User Manual Page | 42
Degree of Protection Against Ingress of Water
The ultrasound probe (P003992 or P003993) is IPX1 below the level of the USB connection.
The transducer lens can be submersed in liquid for testing purposes.
Fig 7.1 Water Protection
IPX1 below this
line
Lens can be
submersed for
testing
