P003948 Uscan User Manual Page | 41
Mode of Operation
NON-CONTINUOUS - The Usc
an enforces non-continuous scanning to maintain safe user enclosure contact
temperatures. Non-continuous scanning is enforced as the enclosure temperature approaches 48°C.
Warning
After storage
at extreme temperatures, check the transducer surface temperature before applying to a
patient. A cold or hot surface may burn a patient.
Caution
Only operate, charge and store Uscan within the approved environmental parameters.
Power Supplies (Chargers)
For the Uscan probe, and tablet the power supply is Signostics Power Supply P003198
Input: 100-240V AC supply 50-60Hz
Output: 5.0V ±0.25V at 2.0A maximum current
The U
scan tablet display may also use the optional HP 18W AC power supply.
Input: 100-240V AC supply 50-60Hz
Output: 12.0V ±0.25V at 1.5A maximum current
For the optional U
scan mobile stand, the power supply is Signostics Power Supply P004016
Input: 100-240V AC supply 50-60Hz
Output: 12.0V ±0.25V at 1.5A maximum current
Internal battery
Ultrasound probe
Signostics Li-ion Polymer Cell
Description: Rechargeable lithium polymer battery
Rating: 3.7V 1350mAh
For the U
scan tablet display, the battery is a 21WHr Li-ion Polymer type.
Measurement accuracy
Measurements reflect a physical property such as area or volume for interpretation by a clinician. They do not
account for variations in acoustic speed of the body, which can vary significantly.
Table 7.6 Accuracy of measurements
Measurement Units Range Accuracy Modes
Distance
Axial cm Full scale ±5% or ± 0.1cm B-mode
Lateral cm Full scale ±5% or ± 0.3cm B-mode
Volume
1
ml 0-999ml ±10% or ± 10ml 3D
1
When used as per instructions scanning a bladder in a tissue equivalent phantom.
