Siko AG05 - Page 61

Communication via SIKONETZ5
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 61 of 64
Para-
meter
no.
[hex]
Name
Access
Format
Description
0x61
Voltage of
control
ro
Integer16
Voltage values in 1/10 V
(see chapter 8: Parameter description 
Parameter no. 51)
0x62
Voltage of
output stage
ro
Integer16
Voltage values in 1/10 V
(see chapter 8: Parameter description 
Parameter no. 52)
0x63
Voltage of
battery
ro
Integer16
Voltage values in 1/100 V
(see chapter 8: Parameter description 
Parameter no. 53)
0x64
Motor current
ro
Integer16
Current values in mA
(see chapter 8: Parameter description 
Parameter no. 54)
0x65
Device code
ro
Unsigned8
0 = AG05
0x66
Display
controller
software
version
ro
Unsigned16
Version number
e. g. 103 corresponds to V1.03
(see chapter 8: Parameter description 
Parameter no. 60)
0x67
Motor
controller
software
version
ro
Unsigned16
Version number
e. g. 108 corresponds to V1.08
(see chapter 8: Parameter description 
Parameter no. 59)
0x68
Serial number
ro
Unsigned32
Serial number
(see chapter 8: Parameter description 
Parameter no. 57)
0x69
Production
date
ro
Unsigned32
Production date in DDMMYYYY format
(see chapter 8: Parameter description 
Parameter no. 58)
0x6A
Gear reduction
ro
Unsigned16
66 = gear 66:1
98 = gear 98:1
0x6B
Actual
position
ro
Integer32
Spindle pitch = 0
values in increments
Spindle pitch > 0
values in 1/100 mm
(see chapter 8: Parameter description 
Parameter no. 55)
0x6C
Actual
rotational
speed
ro
Integer32
Actual speed in rpm
(see chapter 8: Parameter description 
Parameter no. 56)
0x80
Number of
errors
ro
Unsigned8
Returns the number of errors in the error
memory.
(see chapter 8: Parameter description 
Parameter no. 61)
0x81
Error 1
ro
Unsigned8
see chapter 7.2.1: Error codes
(see chapter 8: Parameter description 
Parameter no. 62)
